Page 167 - Accessibility-Accessories
P. 167

Satin finish Basic Grab bars /


            Satin finish Basic straight grab bar                 Satin finish Basic angled grab bar 135°
            Tube Ø 32mm                                          Tube Ø 32mm



















            • Polished satin 304 stainless steel.                • Polished satin 304 stainless steel.
            • Concealed fixings, secured to wall by a 3-hole plate.  • 3 fixing points prevent the hand from getting trapped
            • 10-year warranty.                                   and simplify installation.
            • CE marked.                                         • Concealed fixings, secured to wall by a 3-hole plate.
                                                                 • Dimensions: 400 x 400mm.
                                                                 • 10-year warranty.
                          300 - 600              8,5             • CE marked.
                                                                                    680                  8,5
                            Ø 32
                                                      Ø 72
                                             Ø 32                                                             Ø 72
                                                                                                     Ø 32
                                                  40                               135°
                  35050S/350504S/350505S/350506S                             400                          40
            Basic straight grab bar Ø 32mm                                             400
            Polished satin 304 stainless steel - 300mm  35050S  £46.97
            Polished satin 304 stainless steel - 400mm  350504S  £52.24                 35082S
            Polished satin 304 stainless steel - 500mm  350505S  £56.93  Basic angled grab bar 135° Ø 32mm
            Polished satin 304 stainless steel - 600mm  350506S  £63.10  Polished satin 304 stainless steel  35082S  £84.20


            Satin finish Basic drop-down support rail
            Tube Ø 32mm
                                                                                   Related product
                                                                                   Toilet roll holder for grab bars














            • Polished satin 304 stainless steel.                                  • For toilet rolls.
            • Visible fixings, secured to wall by a 6-hole plate.                  • High-strength polyamide (Nylon).
            • Dimensions : 850 x 300 x 100mm.                                      • Can be fitted without removing the grab bar.  ACCESSIBILITY   BASIC - ECO
            • Wall plate thickness: 3.5mm.                                         • Anti-theft lock.
            • 10-year warranty.                                                    • Anti-rotating locking feature.
            • CE marked.                                                           • For Ø 32 - Ø 34mm bars.
                                                                                   • 10-year warranty.
                                   100          850
                                                                                                   152

                                 300               Ø 32      195                              Ø 32-34  Ø 20  107


                                            35164S                                               510081

                                                                                   Toilet roll holder
                                                                                   for grab bars - HR Nylon   510081  £29.02
            Basic drop-down support rail Ø 32mm - Polished satin 304 stainless steel  35164S  £206.43  bright grey anthracite

                                                                                   Accessibility - Basic & ECO Ranges  165
