Space Guide WCs /


            WCs                                                   Examples of suitable products

            In toilets, a utility space for turning and manoeuvring should be
            envisaged during construction.


            The toilet seat should be installed between 450 and 500mm
            from the floor and at least one support bar, to allow wheelchair
            users to transfer to the toilet seat, should be installed at a height
            between 700 and 800mm. The support bars and their fixings
            should be able to withstand the full weight of an adult.


            A drop-down support rail will facilitate side access.
            We recommend that the length of the support bar should equal
            that of the WC pan plus approximately 150mm. If the toilet   UltraPolish stainless steel   UltraPolish stainless steel
            does not have an exposed cistern, a backrest should be included   drop-down support rail  grab bar 135°, 400 x 400mm
            to avoid any risk of the user falling backwards.      Ref. 510164P               Ref. 5082P


            A rectangular space to manoeuvre, at least 800 x 1,300mm
            should be provided next to the WC pan and a turning space
            of 1,500mm should also be provided to allow a wheelchair to turn
            through 180 degrees.

            We recommend mounting a 400mm grab bar on the back
            of the door to help with closing/opening.


            An electronic flush is ideal for disabled toilets.


            A washbasin equipped with an electronic or time-flow tap/mixer
                                                                        ®
            valve with soft-touch operation, or ergonomic control lever,    Be-Line straight grab bars    WC with 700mm pan
            and with a temperature limiter must be installed      300 - 900mm                Ref. 110710
            (see our catalogues Commercial Water Controls, Water Controls   Ref. 511903, 511904...
            for Hospitals and Stainless Steel Sanitary Ware).


            For DOC M recommendations see pages 61 - 71.













                                                                  Frame system with          TEMPOMATIC WC cross wall
                                                                  TEMPOMATIC dual control    electronic flush valve
                                                                  electronic WC valve        Ref. 463150
                                                                  Ref. 564065DE + 464006









                                                                                                                          SPACE GUIDES






                                                                  Ergonomic toilet brush set  PMR XS washbasin
                                                                  Ref. 510051P               Ref. 120400


                                                                                         Accessibility - Space Guides      175
