Page 27 - Stainless_Steel_Sanitary_Ware

Hand washbasins /

MINIMAL hand washbasin BOB hand washbasin
Wall-mounted - Corner washbasin Wall-mounted with concealed drainage

WASHBASINS

• Wall-mounted hand washbasin for installation in corners (walls at 90°). • Wall-mounted hand washbasin.
• Basin internal diameter: 310mm. • Basin internal diameter: 310mm.
• Clean and simple design. • Clean and simple design.
• Bacteriostatic 304 stainless steel. • Bacteriostatic 304 stainless steel.
• Stainless steel thickness: 1.2mm. • Stainless steel thickness: 1.2mm.
• Rounded edges prevent injury. • Rounded edges prevent injury.
• Supplied with 11/4" waste. • Vandal-resistant: shrouded basin, concealed trap.
• Without overflow. • Quick and easy to install from the front thanks
• Supplied with fixing elements. to a stainless steel mounting frame.
• CE marked. Complies with European standard EN 14688. • Supplied with 1½" waste and trap.
• Weight: 4kg. • Without overflow.
• 30-year warranty. • Supplied with fixing elements.
• CE marked. Complies with European standard EN 14688.
For taps see the DELABIE catalogue "Water Controls for Public and Commercial • Available for cross wall installation in service ducts (see page 84).
Places" (DOC 609UK). • Weight: 5.5kg.
• 30-year warranty.
For taps see the DELABIE catalogue "Water Controls for Public and Commercial
Places" (DOC 609UK).

230
190
420
50 67
130 150 148 120
285

260

Ø 310
Ø 35
340 360

60
220
400
121550 121130

Wall-mounted MINIMAL hand washbasin - Polished satin 304 stainless steel Wall-mounted BOB hand washbasin - Polished satin 304 stainless steel
Without tap hole 120550 £317.90 Without tap hole 120130 £422.37
With central tap hole Ø 35mm 121550 £317.90 With right tap hole Ø 35mm 121130 £422.37
: dispatch within 4 weeks : stock item

Washbasins 25
