/ Deck-mounted TEMPOMATIC MIX electronic controls

TEMPOMATIC MIX
Electronic mains or battery-operated mixer with swivelling spout

• Independent IP65 electronic control unit.
• 230/12V mains supply with transformer or CR123 6V Lithium batteries.
• BIOCLIP models supplied with 2 removable stainless steel spouts L. 185mm.
• Body and spout with smooth interiors (reduces bacterial development).
• Adjustable duty flush (pre-set flush ~60 seconds every 24 hours after last use).
• Flow rate limited to 9 lpm at 3 bar.
• Shock-resistant infrared presence detection sensor.
• Chrome-plated brass body with fixing reinforced by 2 stainless steel rods.
• Hygiene lever L. 100mm controls temperature.
• PEX flexibles with filters and solenoid valves M⅜".
• Anti-blocking security.
• Solenoid valves are upstream of the mixing chamber.
• Suitable for people with reduced mobility.
• 30-year warranty.

Two shut-off options on mains supply models:
Standard mode: timed flow with automatic shut-off.
ON/OFF mode: user shuts off flow voluntarily or automatic shut-off
after 30 minutes of flow.
Thermal shocks are possible.
Pro tip: in ON/OFF mode position the sensor on the side of the mixer.
185
300

110x75x40 
35 max 2
TEMPOMATIC MIX mixer with swivelling spout
Mains supply
BIOCLIP, H. 300mm L. 185mm 20870T3 £731.45 420
H. 305mm L. 250mm 20164T4 £655.85 Quick and easy to install
on BIOCLIP mixers:
Battery-operated  Turn the stainless steel spout
H. 305mm L. 250mm 20464T4 £710.51 3/8" through 90º clockwise then
pull it towards you to remove it.
Options: wastes (see page 97), BIOFIL tap filters (see page 23), 2 Put another spout in its place.
stainless steel spouts or BIOFIL spout filters (see page 66)
20870T3
60 Mixers & taps for sinks
