Page 91 - Water_Controls_for_Healthcare

Wall-mounted sequential mechanical mixers /

Securitouch mixer
Wall-mounted sequential mechanical mixer with ceramic cartridge, internal tubes with smooth interiors

WALL-MOUNTED MIXERS & TAPS

Thermal shock feature

• Sequential over a 70° range: opens and closes with cold water (see page 87). HW CW
• Fixed under spout with BIOSAFE hygienic outlet.
• Spout suitable for fitting a point-of-use filter (see page 23).
• Spout can be made to swivel if required.
• Securitouch thermal insulation prevents burns.
• Ø 35mm ceramic cartridge.
• Pre-set maximum temperature limiter.
• Body and spout with tubes with smooth interiors and very low water volume
(reduces bacterial development).
• Thermal shocks are easy to undertake without removing the control lever
or shutting off the CW supply (see page 13).
• Flow rate regulated at 4 lpm. Smooth tube interior
• Hygiene control lever L. 150mm. with very low water volume
• Supplied with 2 in-line STOP/CHECK wall connectors M½" M¾" (see page 102). from the water inlet to the outlet
= very little biofilm
• Suitable for people with reduced mobility. Thermal insulation
• Mixer requires no non-return valves because the incoming water supplies (HW & CW)
shut off upstream of the mixing chamber (see page 87).
• 30-year warranty.

150 150

120 120
25 max
25 max.
1/2"
150 200
1/2"
1/2"
Wall-mounted Securitouch sequential mechanical mixer with ceramic cartridge 182 175
L. 120mm, 200mm centres 2644P £384.07
L. 120mm, 150mm centres 2640P £351.36
Options: wastes (see page 97), BIOFIL tap filters (see page 23) 2640P 2644P

Wall-mounted mixers & taps 89
