P. 116

/ TEMPOMATIC 4 electronic shower controls


                  •  Exceptional water savings: 80%
                  •  Hygiene: no manual contact, duty flush reduces bacterial development
                  •  Comfort: voluntary or automatic shut-off, rain-effect spray
                  •  Easy to install: modular and adjustable waterproof housing (for different wall finishes)


          TEMPOMATIC 4
          Electronic shower kit with waterproof housing

           NEW                                                 • Tamperproof chrome-plated metal control plate Ø 149mm.
                                                               • Waterproof housing:
                                                                - Collar with waterproof seal.
                                                                - Hydraulic connection from the outside and maintenance from the front.
                                                                - Adjusts to all types of installation (rails, solid walls, panels).
                                                                - Compatible with wall finishes 10 - 120mm
                                                                   (while maintaining the minimum recessing depth of 93mm).
                                                                - Suitable for standard or "pipe-in-pipe" supply.
                                                                - Stopcocks and flow rate adjustment, filter, non-return valve
                                                                   and solenoid valve are all integrated and accessible from the front.
                                                                - Supplied in 2 kits: secure system flush without sensitive elements.
                                                               • TEMPOMATIC 4 shower valve M½" for mixed water supply.
                                                               • Operated by CR123 Lithium 6V batteries or 230/6V mains supply
                                                                (cable and transformer supplied).
                                                               • Infrared presence detector, activated by passing hand in front of sensor.
                                                               • Voluntary activation or automatic shut-off after ~60 seconds.
                                                               • Duty flush (~60 seconds every 24 hours after last use).
                                                               • Flow rate 6 lpm at 3 bar (16 lpm for valve without shower head),
                                                                comfortable rain-effect spray.
                                                               • Chrome-plated, tamperproof ROUND shower head with automatic flow
                                                                rate regulation.
                                                               • Suitable for people with reduced mobility.
                                                               • 30-year warranty.













                                                                             Ø 70                   22 35
                                                                           60
                                                                                                  1/2"
                                                                             175              90-190
                                                                                                       13
                                                                                1/2"
                                                                        150                            149

                                                                                1/2"

                                                                                  443PBOX + 443219





                                                               Product currently under development.
                                                               TEMPOMATIC 4 recessed shower - mains supply
                                                                                                 443SBOX    £156.02
                                                               Kit with shower head
                                                                                                 + 443229   £425.36
                                                                                                 443SBOX    £156.02
                                                               Valve only without shower head
                                                                                                 + 443228   £316.75
                                                               TEMPOMATIC 4 recessed shower - battery-operated
                                                                                                 443PBOX    £147.59
                                                               Kit with shower head
                                                                                                 + 443219   £408.23
                                                                                                 443PBOX    £147.59
                                                               Valve only without shower head
                                                                                                 + 443218   £299.62
                                                               We recommend installing a TMV (see page 143) & floor trap (see page 131)
          114 Showers
