Drop-down support rails /


            Drop-down support rail
































            • For WCs or showers.                                                  Additional products
            • Allows side access in the raised position.
            • In the lowered position use as a grab bar, as a support for standing
             and for assisting movement.
            • NylonClean anti-bacterial treatment: optimal protection against bacterial development.
            • Retained in upright position.
            • Slowed down descent.
            • Suitable for intensive use in public places or the healthcare sector.
            • High-strength polyamide (Nylon) and polymer:
             with 2mm reinforced steel core treated against corrosion.
            • Uniform non-porous surface for easy maintenance and hygiene.
            • Good resistance to chemical products and cleaning.
            • Anti-UV treatment.                                                                    Backrest for WCs
            • Warm to the touch.                                                                    and toilet roll holder
            • Concealed fixings, secured to wall by a 304 stainless steel plate, 4mm thick.         (see pages 151 & 153)
            • Supplied with stainless steel screws for concrete walls.
            • Models with leg: to be used as reinforcement when the wall fixing alone is insufficient.
             Leg folds automatically. Leg height can be adjusted from 760 - 780mm.
             Dimensions: 850 or 650 x 800 x 105mm, Ø 32mm.
            • Models without leg: 850 or 650 x 230 x 105mm, Ø 32mm.
            • Tested to over 200kg. Maximum recommended user weight: 135kg.                                               ACCESSIBILITY   NYLON CLEAN
            • 10-year warranty.
            • CE marked.                                                           Related product
                                                                  650/850
                            105
                            105                                   650/850
                                                                                                    Cover plate
                          230  230                                            180  180              • Conceals the fixing
                                                                                                      screws when
                                                         17    Ø 32                                   the drop-down
                                                         17
                                                               Ø 32
             750/950  750/950   650/850                 800/1000 800/1000      760/780  760/780       support rail
                                                                                                      is removed.
                                650/850
                                                                                                    • Reduces the number
                                                                                                      of rails in a facility,
                                           180  180
                                                                                                      allowing installation
                 242  17
                 242
                      17
                                Ø 32                                                                  only when required.
                                Ø 32
                                                  300
                                                  300
                                                                                                    • Supplied with
                                                                                        105           stainless steel screws
                                                             N
                                                             2
                                                                 0
                                                                7
                                                               5
                                                              /
                                                                1
                          0
                           N
                           /
                        1
                        5 5160N/5164N N                    5 5162N/5170N N                   17
                         6
                              4
                                                           1
                                                            6
                            5
                             1
                             6
                                                                                                      for concrete walls.
                                                                                                    • 10-year warranty.
                                                                                      230
            Drop-down support rail with concealed fixings Ø 32mm without leg
            Bright white HR Nylon - L. 650mm                      5160N   £322.76
            Bright white HR Nylon - L. 850mm                      5164N   £343.92
                                                                                        510150N
            Drop-down support rail with concealed fixings Ø 32mm with leg
            Bright white HR Nylon - L. 650mm                      5162N    £439.16
                                                                                   Nylon cover
            Bright white HR Nylon - L. 850mm                      5170N   £461.07  with fixing plate  510150N  £43.08
                                                                                     Accessibility - NylonClean Range  141
