Page 149 - Accessibility-Accessories

Shower grab bars /

Two-wall grab bar with vertical riser rail
For shower seats

Additional products

Removable shower
seat (see page 133),
sliding shower head
holder, sliding soap
dish and shower shelf
with glove holder
(see page 151)

• For showers.
• Can support a removable shower seat (order separately).
• Use as a grab bar and to support the user in an upright position.
• Helps and secures entry and movement in the shower. 8,5
• Use as a shower riser rail by adding a sliding shower head holder and/or soap dish. Ø 73
• NylonClean anti-bacterial treatment: optimal protection against bacterial development.
• Model with sliding riser rail: upright position can be adjusted Ø 32 ACCESSIBILITY NYLON CLEAN
during installation. Can be moved to the left or the right in order 38
to adapt the space (positioning of shower, depth of shower seat...).
• Can be installed with the upright on the left or the right.
• Suitable for intensive use in public places or the healthcare sector.
• High-strength polyamide (Nylon):
with 2mm reinforced steel core treated against corrosion.
• Uniform non-porous surface for easy maintenance and hygiene.
• Good resistance to chemical products and cleaning.
• Anti-UV treatment. Warm to the touch. 150 600
• 38mm gap between the bar and the wall: 750
minimal space prevents the forearm passing between the bar
and the wall, reducing the risk of fracture in case of loss of balance. 5481N/5490N
• Concealed fixings, secured to wall by a 6-hole plate, Ø 73mm.
• Supplied with stainless steel screws for concrete walls.
• Dimensions: 1,150 x 750 x 750mm, Ø 32mm. 1150
• Tested to over 200kg. Maximum recommended user weight: 135kg.
• 10-year warranty.
• CE marked.
Upright can be adjusted
left or right (Ref. 5481N)

Two-wall grab bar Ø 32mm - Bright white HR Nylon - For shower seats 350 400
With sliding riser rail 5481N £412.73 750
With fixed riser rail 5490N £372.41
5490N
Accessibility - NylonClean Range 147
