Page 150 - Accessibility-Accessories
P. 150

/ Shower grab bars


              Two-wall corner grab bar
              For shower seats































              • For WCs, showers or baths.                                           Additional products
              • Can support a removable shower seat (order separately).
              • Use as a grab bar and to support the user in an upright position.
              • Helps and secures entry and movement in the shower or bath.
              • Helps with the transfer from a wheelchair to the toilet seat for WCs
               with recessed cisterns or direct flush.
              • NylonClean anti-bacterial treatment: optimal protection against bacterial development.
              • Suitable for intensive use in public places or the healthcare sector.
              • High-strength polyamide (Nylon):
               with 2mm reinforced steel core treated against corrosion.
              • Uniform non-porous surface for easy maintenance and hygiene.
              • Good resistance to chemical products and cleaning.
              • Anti-UV treatment.
              • Warm to the touch.
              • 38mm gap between the bar and the wall:
               minimal space prevents the forearm passing between the bar and the wall,
               reducing the risk of fracture in case of loss of balance.
              • Concealed fixings, secured to wall by a 6-hole plate, Ø 73mm.
              • Supplied with stainless steel screws for concrete walls.
              • Dimensions: 750 x 750mm, Ø 32mm.
              • Tested to over 200kg. Maximum recommended user weight: 135kg.
              • 10-year warranty.                                                                     Removable shower
              • CE marked.                                                                            seat (see page 133)
                                                                                                      and shower shelf with
                                                                8,5
                                                                                                      glove holder
                                                                    Ø 73                              (see page 151)
                                                            Ø 32
                                                                 38

                                                          150      600
                                                      150
                                                                     Ø 32


                                                      600



                                Installation example
                                for showers                    5121N



              Two-wall corner grab bar Ø 32mm - Bright white HR Nylon - For shower seats  5121N  £235.60
