Page 54 - Accessibility-Accessories
P. 54

/ Basic grab bars


              Satin finish Basic straight grab bar                 Satin finish Basic angled grab bar 135°
              Tube Ø 32mm                                          Tube Ø 32mm



















              • Polished satin 304 stainless steel.                • Polished satin 304 stainless steel.
              • Concealed fixings, secured to wall by a 3-hole plate.  • 3 fixing points prevent the hand from getting trapped
              • 10-year warranty.                                   and simplify installation.
              • CE marked.                                         • Concealed fixings, secured to wall by a 3-hole plate.
                                                   8,5
                                                                   • Dimensions: 400 x 400mm.
                                                        Ø 72       • 10-year warranty.
                            300 - 600                              • CE marked.
                              Ø 32             Ø 32                                  680               8,5
                                                    40
                                                                                                            Ø 72
                            35050S/350504S/350505S/350506S                           135°
                                                                                                   Ø 32
                                                                               400
                                                                                                        40
              Basic straight grab bar Ø 32mm                                             400
              Polished satin 304 stainless steel - 300mm   35050S  £46.97                 35082S
              Polished satin 304 stainless steel - 400mm   350504S  £52.24
              Polished satin 304 stainless steel - 500mm  350505S  £56.93  Basic angled grab bar 135° Ø 32mm
              Polished satin 304 stainless steel - 600mm   350506S  £63.10  Polished satin 304 stainless steel  35082S  £84.20


              White powder-coated Basic straight grab bar          White powder-coated Basic angled grab bar 135°
              Tube Ø 32mm                                          Tube Ø 32mm


















              • White powder-coated.                               • White powder-coated.
              • Concealed fixings, secured to wall by a 3-hole plate.  • 3 fixing points prevent the hand from getting trapped
              • 10-year warranty.                                   and simplify installation.
              • CE marked.                                         • Concealed fixings, secured to wall by a 3-hole plate.
                                                   8,5             • Dimensions: 400 x 400mm.
                                                                   • 10-year warranty.
                                                        Ø 72
                            300 - 600                              • CE marked.
                              Ø 32             Ø 32                                  680
                                                    40                                                8,5
                           35050W/350504W/350505W/350506W                     400   135°    Ø 32           Ø 72
                                                                                                   Ø 32
                                                                                        400            40
              Basic straight grab bar Ø 32mm
              White powder-coated - 300mm        35050W    £39.90
                                                                                   35082W
              White powder-coated - 400mm        350504W    £47.75
              White powder-coated - 500mm        350505W   £51.06
                                                                   Basic angled grab bar 135° Ø 32mm
              White powder-coated - 600mm        350506W   £58.58  White powder-coated                 35082W    £81.39
              52  Hygienic accessories
