Page 83 - Accessibility-Accessories
P. 83

Grab bars /


            Angled grab bar 135°






























                                                                                                                          ACCESSIBILITY


              Metallised                                                                                                   BE-LINE ®
              anthracite



             Matte white

            • For WCs, showers or baths.
            • For use as a handrail (horizontal part) or as a grab bar (135° part).
            • Universal for either left or right side.
            • Aluminium tube thickness 3mm. Solid aluminium fixing points.
            • Rounded profile Ø 35mm with ergonomic flat front face
             that prevents rotation for an optimal grip.
            • Choice of powder-coated metallised anthracite (LRV 14) or matte white (LRV 82) finish;
             provides a good visual contrast with the wall.
            • Uniform surface for easy maintenance and hygiene.
            • 38mm gap between the bar and the wall:
             minimal space prevents the forearm passing between the bar
             and the wall, reducing the risk of fracture in case of loss of balance.
            • 3 fixing points prevent the hand from getting trapped and simplify installation.
            • Concealed fixings.
            • Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
                                                                                                   785
            • Dimensions: 400 x 400mm or 220 x 220mm.                                              685
            • Tested to over 200kg. Maximum recommended user weight: 135kg.
            • 10-year warranty.                                                      38
            • CE marked.                                                            35   283       135°
                                                                                                          400  455
                                                                                               400
                                                                                               455

                                                                                                 511982




                                                                                                   480
                                                                                                   375
            Angled grab bar 135° - 400 x 400mm                                                     135°
            Metallised anthracite powder-coated aluminium   511982C  £141.19                 156
            Matte white powder-coated aluminium         511982W   £141.19                               220  275
                                                                                                 220
            Angled grab bar 135° - 220 x 220mm                                                   275
            Metallised anthracite powder-coated aluminium   511983C  £127.54
            Matte white powder-coated aluminium         511983W   £127.54
                                                                                                 511983
                                                                                       Accessibility - Be-Line range  81
                                                                                                         ®
   78   79   80   81   82   83   84   85   86   87   88
