Page 87 - Accessibility-Accessories
P. 87

Drop-down support rails /


            Drop-down support rail


             NEW                                                                      Additional products

                                                                                       NEW










                                                                                       NEW              WC backrest and
                                                                                                        toilet roll holder
                                                                                                        (see page 93)


              Metallised
              anthracite


                Matte
                white

            • For WCs or showers.                                                     Related product
            • Allows side access in the raised position.                                                                  ACCESSIBILITY
            • In the lowered position use as a grab bar, as a support for standing    Cover plate                          BE-LINE ®
             and for assisting movement.
            • Removable: easy to remove with anti-theft locking system. Reduces the number of bars    NEW
             in a facility, allowing installation only when required e.g. hotels or hospitals providing short-term
             accommodation for people with reduced mobility.
            • Slowed down descent. Retained in upright position.
            • Aluminium tube.
            • Rounded profile Ø 42mm with ergonomic flat front face that prevents rotation for an optimal grip.
            • Choice of powder-coated metallised anthracite (LRV 14) or matte white (LRV 82) finish;
             provides a good visual contrast with the wall.
            • Uniform surface for easy maintenance and hygiene.
            • Concealed fixings secured to wall by a 304 stainless steel plate, 5mm thick.  • Conceals fixing screws when the drop-
            • Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
                                                                                       down support rail is removed.
            • Models with leg: to be used as reinforcement when the wall fixing alone is insufficient.    • Reduces the number of drop-down
             Dimensions: 850 or 650 x 825 x 120mm. Leg height can be adjusted from 760 - 780mm.
            • Models without leg: 850 or 650 x 202 x 120mm.                            support rails in a facility, allowing
            • Tested to over 200kg. Maximum recommended user weight: 135kg.            installation only when required.
                                                                                       Example: hotels or hospitals providing
            • 10-year warranty. CE marked.
                                                                                       short-term accommodation for people
                                                                                       with reduced mobility.
                                                               120        650-850
                                                                                      • Model with fixing plate: supplied with
                                                                                       stainless steel screws for concrete walls.
                                                                 202
                                                                                      • 10-year warranty.
               720-920                               905-1105                   760-780           105   17
                        120          650-850
                      202                                                                      230
                              23      Ø42
                109                                     143
                          511960/511964                        511962/511963
                                                                                                   511950
            Drop-down support rail without leg
            Metallised anthracite powder-coated aluminium - L. 650mm  511960C  £327.74
            Metallised anthracite powder-coated aluminium - L. 850mm  511964C  £352.02
                                                                                      Cover without fixing plate
            Matte white powder-coated aluminium - L. 650mm          511960W   £327.74
                                                                                      Metallised
            Matte white powder-coated aluminium - L. 850mm          511964W  £352.02  anthracite     511950C   £50.12
            Drop-down support rail with leg                                           Matte white    511950W   £50.12
            Metallised anthracite powder-coated aluminium - L. 650mm  511962C  £390.79
                                                                                      Cover with fixing plate
            Metallised anthracite powder-coated aluminium - L. 850mm  511963C  £413.30  Metallised
            Matte white powder-coated aluminium - L. 650mm          511962W   £390.79  anthracite   511950FC   £93.15
            Matte white powder-coated aluminium - L. 850mm          511963W   £413.30  Matte white  511950FW   £93.15

                                                                                                         ®
                                                                                       Accessibility - Be-Line range  85
   82   83   84   85   86   87   88   89   90   91   92
