Page 92 - Accessibility-Accessories
P. 92

/ Shower grab bars


              Two-wall corner grab bar

































                Metallised
                anthracite



                  Matte
                  white

              • For WCs, showers or baths.                                           Additional product
              • Use as a grab bar and to support the user in an upright position.
              • Helps and secures entry and movement in the shower also with getting
               in and out of the bath.                                                NEW
              • Helps with the transfer from a wheelchair to the toilet seat,
               for WCs with recessed cisterns or direct flush.
              • Aluminium tube thickness 3mm. Solid aluminium fixing points.
              • Rounded profile Ø 35mm with ergonomic flat front face
               that prevents rotation for an optimal grip.
              • Choice of powder-coated metallised anthracite (LRV 14) or matte white (LRV 82) finish;
               provides a good visual contrast with the wall.
              • Uniform surface for easy maintenance and hygiene.
              • 38mm gap between the bar and the wall:                               Shower shelf with glove holder
               minimal space prevents the forearm passing between the bar            (see page 92)
               and the wall, reducing the risk of fracture in case of loss of balance.
              • Concealed fixings.
              • Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
              • Dimensions: 695 x 695mm.
              • Tested to over 200kg. Maximum recommended user weight: 135kg.
              • 10-year warranty.
              • CE marked.

                                                                                                  750
                                                                                                  695
                                                                                                   565
                                                                                                         38
                                                                                                      35



                                                                                       750  695



              Two-wall corner grab bar
              Metallised anthracite powder-coated aluminium   511941C  £216.51
              Matte white powder-coated aluminium         511941W  £216.51
                                                                                              511941
