Page 93 - Accessibility-Accessories
P. 93

Shower grab bars /


            Two-wall grab bar with sliding vertical riser rail


                                                                                   Additional products

                                                                                                      NEW










                                                                                    NEW             Sliding shower head
                                                                                                    holder, sliding soap
                                                                                                    dish and shower shelf
                                                                                                    with glove holder
                                                                                                    (see page 92)







                                                                                                                          ACCESSIBILITY   BE-LINE ®






                                                                                                             38
                                                                                                           35
              Metallised
              anthracite


                Matte
                white


            • For showers.
            • Use as a grab bar and to support the user in an upright position.
            • Helps and secures entry and movement in the shower.
            • Use as a shower riser rail by adding a sliding shower head holder
                                                                                                  695
             and/or a soap dish.
                                                                                                  750
            • Upright position can be adjusted during installation:
             can be moved to the left or the right in order to adapt the space
             (positioning of shower, depth of shower seat...).                                   511949
            • Can be installed with the upright on the left or the right.
            • Aluminium tube thickness 3mm. Solid aluminium fixing points.
            • Rounded profile Ø 35mm with ergonomic flat front face
             that prevents rotation for an optimal grip.
            • Choice of powder-coated metallised anthracite (LRV 14)
             or matte white (LRV 82) finish; provides a good visual contrast
             with the wall.
            • Uniform surface for easy maintenance and hygiene.
            • 38mm gap between the bar and the wall:
             minimal space prevents the forearm passing between the bar
             and the wall, reducing the risk of fracture in case of loss of balance.  1185
            • Concealed fixings.                                                        1130
            • Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.  Upright can be moved
            • Dimensions: 1,130 x 695 x 695mm.                    to the left or the right
            • Tested to over 200kg. Maximum recommended user weight: 135kg.
            • 10-year warranty.
            • CE marked.


            Two-wall grab bar with sliding vertical riser rail                                   695
                                                                                                  750
            Metallised anthracite powder-coated aluminium        511949C  £331.80
            Matte white powder-coated aluminium                  511949W  £331.80
                                                                                                 511949
                                                                                                         ®
                                                                                       Accessibility - Be-Line range  91
