Page 96 - Stainless_Steel_Sanitary_Ware

/ Vandal-resistant urinals

DELTA HD urinal DELTA TC urinal
Rimless Rimless

• Wall-hung individual rimless urinal. • Wall-hung individual rimless urinal, cross wall installation for service ducts.
• Compatible with all standard frame systems on the market. • Bacteriostatic 304 stainless steel. Stainless steel thickness: 1.2mm.
• Bacteriostatic 304 stainless steel. Stainless steel thickness: 1.2mm. • Rear (recessed) water inlet.
• Rear (recessed) water inlet. • Vandal-resistant: recessed waste outlet, concealed trap.
• Vandal-resistant: recessed waste outlet, concealed trap, • 200mm threaded rod can be cut to size (other lengths available on request).
and reinforced mounting frame. • Supplied with fixing elements.
• Quick and easy to install from the front thanks to a stainless steel • CE marked. Complies with European standard EN 13407 for 2L flush.
mounting frame. • Weight: 8kg.
• Supplied with 1½" P trap, fixing elements and theft prevention TORX • 30-year warranty.
security screws.
• CE marked. Complies with European standard EN 13407 for 2L flush. For urinal valves see the DELABIE catalogue "Water Controls for Public
• Weight: 7.5kg. and Commercial Places" (DOC 609UK).
• 30-year warranty.

For valves, see recommendations for individual urinals on page 59.

65 220 65 220
180
112 450 100
450
345 180 420 220
585 585

Ø 32

350 385
350 160
385

164770 160770

Wall-hung DELTA HD urinal 164770 Wall-hung DELTA TC urinal 160770
Recessed water inlet - Pol. satin 304 st. steel £668.00 Recessed water inlet - Pol. satin 304 st. steel £668.00
: dispatch within 4 weeks : stock item

94 Secure sector
