/ SECURITHERM sequential thermostatic mixers

100% WATERPROOF, THE H9633L RECESSED SEQUENTIAL IS WELL
CONNECTED!
BIOSAFE
Improved ergonomics and functionality Thermal shock feature
The same lateral movement, through a 180° range, With SECURITHERM sequential thermostatic mixers,
opens the water flow and adjusts the temperature. it is possible to undertake thermal shocks at
the temperature of the hot water in the system.
Opens and closes with cold water Remove the control lever to override the temperature
SECURITHERM sequential mixers open and close limiter.
with cold water for increased anti-scalding safety.
Temperature stability
Cold water SECURITHERM sequential thermostatic mixers
Opening with cold water, without any passage of hot ensure stable temperatures regardless of pressure
water, ensures the supply of only cold water if required. and flow rate variations in the system. They respond
immediately to any changes.
BIOSAFE: infection control In addition, they prevent cold showers ensuring that
HW/CW cross flow is impossible the cold water supply shuts off if the hot water supply
DELABIE has developed a unique system that fails.
enables sequential thermostatic mixers to shut off
the Hot Water and Cold Water directly at the inlets, 100% waterproof
Sequential control to open/close making non-return valves redundant. Cross flow Standard housings on the market are designed to be
between the HW and CW is impossible. This reduces cut to size flush to the wall, which increases the risk of
the risk of bacterial development considerably. leaks between the wall and the collar.
For more information see page 7. DELABIE's recessed housing is equipped with a collar
with integrated seal that clips onto the housing once
Low volume of standing water in the body the wall finish is in place (patented system).
Sequential thermostatic mixers have just one It is completely waterproof without silicone.
mechanism instead of two like dual control models. Any condensation is evacuated via the plate.
As a result, fewer components are in contact with The wall stays intact throughout.
the water and there is less standing water in the mixer. The H9633L recessed sequential mixer is fitted with an
The risk of bacterial development is reduced. elbow outlet which connects directly onto the control
plate: the product is therefore 100% waterproof.
Body with smooth interior
Automatic anti-scalding failsafe
SECURITHERM thermostatic technology ensures Modular
immediate hot water shut-off if the cold water supply DELABIE's recessed housing can be attached from
fails. If the cold water supply fails, the European the sides, front or back, to be fixed to plasterboard
standard EN 1111 allows a slight leak of hot water rails, load-bearing walls or even thin panels. The
(0.10L/10 seconds). installation is therefore modular, and adapts to suit
With DELABIE's thermostatic mixers, the hot water any project.
shut-off is complete (with no trickle of water).
If the hot water supply fails, DELABIE's
SECURITHERM mixers also shut off the cold water
supply. This avoids the risk of cold showers which may
Auto-draining device result in a loss of balance or a fall.

Maximum temperature limiter
DELABIE's sequential thermostatic mixers are
supplied with a pre-set maximum temperature Plasterboard rails Load-bearing walls Thin panels
YEAR limiter. The user cannot increase the temperature
above the maximum set temperature, reducing the
risk of scalding.
Adaptable
The ideal positioning of the collar allows the housing
WARRANTY
to be cut to size lengthwise depending on the
wall thickness, whilst still guaranteeing complete
waterproofing. The housing adapts to all wall depth
requirements, thick or thin, from 10 to 120mm.
Quick and easy to install
The recessed sequential mixer can be connected
to standard pipes or "pipe-in-pipe".
The hydraulic connection is made from the outside
of the housing. During the installation, the sequential
cartridge and filter are replaced by a temporary
casing to facilitate and ensure a safe system flush,
without damaging the technical elements.
Find out more about our range of mixers
with retracting hand sprays on pages 73 - 77. 30-year warranty against any manufacturing defects.
50 years repairability.

110 Thermostatic shower mixers
