/ Connectors

Auto-draining device STOP/CHECK connectors Standard offset connectors
For showers and shower-bath mixers Wall-mounted connectors M½" M¾" Wall-mounted connectors M½" M¾"

• Automatically drains the shower head • Chrome-plated brass connectors Ø 65mm, • Chrome-plated standard offset connectors
and flexible hose. for wall-mounted mixers. for wall-mounted mixers.
• Prevents water stagnation and reduces • M½" M¾". • M½" M¾".
bacterial development (for more information, • Supplied in packs of 2. • Chrome-plated brass.
see page 107). • Ideal for hospitals. • Supplied in packs of 2.
• Chrome-plated brass body with downstream purge. • 30-year warranty. • 30-year warranty.
• Inlet F½" with filter
(to connect to the bottom outlet of the mixer). Connectors include:
• Outlet M½" (to connect to the flexible hose). Manual escutcheon control:
• 30-year warranty. stopcock position and/or non-return valve check.
STOP function:
We recommend using the auto-draining device with - Allows isolation of the water supply so that
a short flexible hose (ref. 834T3 or 836T3, page 137) the mixer can be easily removed for descaling,
cleaning or maintenance.
- Automatic anti-scalding safety can be checked
on SECURITHERM thermostatic and EP
pressure-balancing mixers.
CHECK function:
Allows non-return valves to be checked
on the respective mixer (DELABIE patent).

Ø 65 Ø 64
Ø 44 1/2"
3/4" 3/4"
1/2" 1/2"
11
1/2"
35 max 15 max
50
90
880 855755UK.2P 856794.2P

Standard connectors
STOP/CHECK connectors Centres 11mm, L. 50, Ø 64 856794.2P £33.37
In-line 855755UK.2P £72.28 Centres 11mm, L. 50, Ø 70 856127.2P £21.29
Auto-draining device 880 £41.36 Offset, 12mm centres 855755.2P £60.81 Centres 12mm, L. 60, Ø 70 856027.2P £38.05

138 Shower accessories
