/ Electronic basin controls

SPECIFICALLY DESIGNED FOR
COMMERCIAL ENVIRONMENTS

Resistant to intensive use and vandalism Reliable presence detection
DELABIE’s electronic mixers and taps are specifically DELABIE has chosen the most reliable detection
designed to withstand intensive use as well as system: infrared active pulse. It cannot be adjusted
voluntary and involuntary vandalism. or affected by variations in light levels. On models
The mixer and tap bodies are made from chrome- with a sensor at the end of the spout, the infrared
plated metal, fitted with shock-resistant mechanisms beam adapts automatically, to ensure that hands are
Vandal-resistant and sensors. The reinforced fixings will stand up to detected in any position. DELABIE has incorporated
intensive use. a telemetric laser cell into certain models, for optimal
Streamlined designs prevent unwanted removal. presence detection.
To prevent abuse and wasted water, all models are
fitted with a system to prevent blocking during flow. Minimal servicing and simple to maintain
For areas that require tamperproof installations, The scale-resistant components (flow straighteners,
there are recessed and cross wall versions with aerators, internal mechanisms) and filters ensure that
mechanisms that cannot be accessed by the user. minimal servicing is required. Maintenance is easier.
The spare parts are standardised to ensure quick and
Easy to install easy replacement by maintenance staff.
DELABIE's products are easy to install The electronic control units are fitted with LEDs to aid
and adjustments are kept to a minimum in order diagnostic checks, and access to the components
Reinforced fixing
to save time during installation. (batteries, solenoid valve) is direct, without having
to remove the mixer/tap.
• Independent electronic control unit:
BINOPTIC, TEMPOMATIC, TEMPOMATIC 2
and PRO models Technical characteristics
Depending on the model, there is an option to adjust Operating pressure 1 - 5 bar, 3 bar recommended
the presence detection distance, to change
the operating mode (ON/OFF or automatic) Pressure differential ∆P < 1 bar
and change the duty flush settings. CW / HW
The battery-operated models work autonomously Electrical supply* 230V / 50 Hz class II
for 3 to 6 years. (without earth connection)
The electronic control units are waterproof (IP65)
Diagnostic LED with diagnostic LEDs to facilitate servicing. Electronic unit* Independent waterproof IP65
• Electronic unit and solenoid valve integrated CR 123 standard batteries
in the body of the mixer/tap*: 6V Lithium battery* Average lifespan ~350,000 cycles
BINOPTIC 2, TEMPOMATIC 4 and 5 models or 3 to 6 years
Can be installed on any isolated point-of-use,
for new builds as well as renovation. Duty flush programme 60 seconds
can be adjusted* 12 or 24 hours after last use (or OFF)
- 6V Lithium batteries*:
There are no electrical connections required. Automatic shut-off Prevents blocking
Simply connect the flexibles to the supply pipes in event of negligence in the open position
in the same way as for a conventional mixer/tap. Temperature limiter Can be adjusted
No special adjustment is necessary, the mixer/tap
Simple to maintain is ready to operate independently for 3 to 6 years. HW supply 55°C max
A red LED will flash for 15 days to indicate that Recommended installation
110 - 200mm
the battery life is low. The batteries can be height for wall-mounted above base of bowl
changed without shutting off the water supply mixers/taps
or removing the mixer/tap. Complies with European directives
YEAR The batteries are directly accessed through the and BT 2014/35/UE
CEM 2014/30/UE
head of the tap (TEMPOMATIC 4), or via a battery
pack attached to the flexibles (BINOPTIC 2 and * Depending on model
WARRANTY TEMPOMATIC 5).
- 230/6V mains supply (plug in or recessed)*: 30-year warranty against any manufacturing defects.
To operate, simply connect the flexibles to the 50 years repairability.
supply pipes and connect the electrical supply
to the mixer/tap via a plug and socket or recessed DESIGN
connection close to the basin.
This does not require any specific maintenance
YEARS (no battery changes). DELABIE’s products, known for their endurance
and reliability, have a timeless design.
with any commercial installation.
REPAIRABILITY * Depending on model The diversity of the product range fits in perfectly
In an office building or a shopping centre it is paramount
that the product design fits in with its surroundings.
Aesthetic products are subject to less vandalism
as they are better respected. The smooth shape
of the mixers and taps reduces the build-up of dirt
and facilitates cleaning. Easy but secure access
to the control mechanisms provides easy maintenance.

20 Basins
