TEMPOSTOP MIX 4 / TEMPOSTOP 4 time flow basin controls /

• Exceptional water savings: 85%
• Vandal-resistant: chrome-plated solid brass, reinforced fixings, anti-blocking (AB) system
• Comfort: side temperature control lever on mixer models

TEMPOSTOP MIX 4 / TEMPOSTOP 4
Deck-mounted time flow basin controls

NEW BASINS

• Time flow ~7 seconds.
• Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
• Tamperproof, scale-resistant flow straightener.
• Chrome-plated brass body.
• PEX flexibles with filters and non-return valves (mixers).
• Fixing reinforced by 2 stainless steel rods (mixers). Standard lever
• Side temperature control lever with adjustable maximum temperature
limiter (mixers).
• Available with anti-blocking (AB) system: water will only flow when
push-button is released.
• 30-year warranty.

Product currently under development.
TEMPOSTOP MIX 4 mixer
With stopcocks
Side temperature control lever 704900 £266.33
Side temperature control lever 704900AB
and AB anti-blocking system £275.78
Without stopcocks
Side temperature control lever 704910 £254.52
Side temperature control lever 704910AB £263.97
and AB anti-blocking system 70
70 30 max
M⅜'' connection Ø 15mm for compression fittings 803815.2P £10.00 Ø45
(2 pieces) Ø45 50
TEMPOSTOP 4 tap 105 1/2" 105 45 max
Fixing with back-nut 704100 £178.38 410
Fixing reinforced by 3 stainless steel screws and AB 704100AB £187.83
anti-blocking system 3/8"
We recommend installing a TMV for taps (see page 143)
704100 704900

Basins 63
