Page 107 - Accessibility-Accessories
P. 107

Grab bars /


            Straight grab bar



































             UltraPolish



              UltraSatin

            • For WCs, showers or baths.
            • For use as a handrail, grab bar or support rail.                                                            ACCESSIBILITY    STAINLESS STEEL
            • Bacteriostatic 304 stainless steel tube.
            • Stainless steel with UltraPolish bright polished finish or UltraSatin polished satin finish,
             uniform non-porous surface for easy maintenance and hygiene.
            • Plate welded to the tube by invisible safety bead weld (process exclusive to "ArN-Securit").
            • 40mm gap between the bar and the wall: minimal space prevents the forearm passing between
             the bar and the wall, reducing the risk of fracture in case of loss of balance.
            • Concealed fixings, secured to wall by a 3-hole plate, Ø 72mm.
             Fixing plates and cover plates in 304 stainless steel.
            • Supplied with stainless steel screws for concrete walls.
            • Dimensions: 300 - 900mm centre-to-centre.
            • Ø 32mm models, 300 - 600mm: tested to over 250kg. Maximum recommended
             user weight: 170kg. Ø 32mm models, 900mm: maximum recommended user weight: 135kg.
             Ø 25mm models: maximum recommended user weight: 115kg.
            • 10-year warranty. CE marked.
            Straight grab bar Ø 32mm - UltraPolish
            UltraPolish bright polished stainless steel - 300mm  5050P2  £67.19
            UltraPolish bright polished stainless steel - 400mm  50504P2  £72.87
            UltraPolish bright polished stainless steel - 500mm  50505P2  £78.56
            UltraPolish bright polished stainless steel - 600mm  50506P2  £84.26
            UltraPolish bright polished stainless steel - 900mm  50509P2  £101.34                        8,5
                                                                                  8,5
            Straight grab bar Ø 32mm - UltraSatin
            UltraSatin polished satin stainless steel - 300mm  5050S  £67.19           Ø 72                   Ø 72
                                                                                                     Ø 25
            UltraSatin polished satin stainless steel - 400mm  50504S  £72.87  Ø 32
                                                                                                          40
            UltraSatin polished satin stainless steel - 500mm  50505S  £78.56      40
            UltraSatin polished satin stainless steel - 600mm  50506S  £84.26
            UltraSatin polished satin stainless steel - 900mm  50509S  £101.34  5050/50504          5055P2/5056P2
                                                                             50505/50506/50509    5057P2/5058P2/5059P2
            Straight grab bar Ø 25mm - UltraPolish
            UltraPolish bright polished stainless steel - 300mm  5055P2  £64.98
                                                                                             300-900
            UltraPolish bright polished stainless steel - 400mm  5056P2  £69.14
            UltraPolish bright polished stainless steel - 500mm  5057P2  £74.73
            UltraPolish bright polished stainless steel - 600mm  5058P2  £82.94
            UltraPolish bright polished stainless steel - 900mm  5059P2  £90.98     5050/50504/50505/50506/50509
                                                                                  5055P2/5056P2/5057P2/5058P2/5059P2
                                                                                  Accessibility - Stainless Steel Range  105
