Grab bars /


            Angled grab bar 135°






























             UltraPolish


              UltraSatin



               White
            powder-coated

            • For WCs, showers or baths.
            • For use as a handrail (horizontal part) or as a grab bar (135° part).                                       ACCESSIBILITY    STAINLESS STEEL
            • Universal for either left or right side.
            • Bacteriostatic 304 stainless steel tube.
            • Stainless steel with UltraPolish bright polished finish or UltraSatin polished satin finish,
             uniform non-porous surface for easy maintenance and hygiene.
            • Plate welded to the tube by invisible safety bead weld
             (process exclusive to "ArN-Securit").
            • 40mm gap between the bar and the wall:
             minimal space prevents the forearm passing between the bar              8,5             8,5
             and the wall, reducing the risk of fracture in case of loss of balance.
            • Models with 3 fixing points: prevents the hand from getting trapped and     Ø 72   Ø 25     Ø 72
             simplifies installation.                                            Ø 32                 40
            • Concealed fixings, secured to wall by a 3-hole plate, Ø 72mm.           40
             Fixing plates and cover plates in 304 stainless steel.
            • Supplied with stainless steel screws for concrete walls.           5081/5082/5083   5086/5087
            • Dimensions: 400 x 400mm or 220 x 220mm.
            • Models with 3 fixing points, Ø 32mm: tested to over 250kg, max. recommended
             user weight: 170kg. Models with 2 fixing points, Ø 32mm: max. recommended user
             weight: 135kg. Ø 25mm models: max. recommended user weight: 115kg.
            • 10-year warranty. CE marked.                                        680                    680

            Angled grab bar 135° 2 fixing points - Ø 32mm                                  283                     283
                                                                                 135°
                                                                                                        135°
                                                                             400
                                                                                                   400
            UltraPolish bright polished stainless steel - 400 x 400mm  5081P2  £97.00
            UltraPolish bright polished stainless steel - 220 x 220mm  5083P  £92.62  400                   400
            UltraSatin polished satin stainless steel - 400 x 400mm  5081S  £97.00
            UltraSatin polished satin stainless steel - 220 x 220mm  5083S  £92.62
                                                                                 5081/5086             5082/5087
            Angled grab bar 135° 3 fixing points - Ø 32mm
            UltraPolish bright polished stainless steel - 400 x 400mm  5082P  £111.55
            UltraSatin polished satin stainless steel - 400 x 400mm  5082S  £111.55         375
            White powder-coated stainless steel - 400 x 400mm  5082W  £135.39
                                                                                            135°  156
            Angled grab bar 135° 2 fixing points - Ø 25mm                                220
            UltraPolish bright polished stainless steel - 400 x 400mm  5086P2  £78.05         220
            Angled grab bar 135° 3 fixing points - Ø 25mm
            UltraPolish bright polished stainless steel - 400 x 400mm  5087P  £89.59
                                                                                            5083
