Page 110 - Accessibility-Accessories
P. 110

/ Grab bars


              Angled grab bar 90°



































               UltraPolish



               UltraSatin

              • For WCs or baths.
              • For use as a handrail (horizontal part) or as a grab bar (vertical part).
              • Universal for either left or right side.
              • Bacteriostatic 304 stainless steel tube.
              • Stainless steel with UltraPolish bright polished finish or UltraSatin polished satin finish,
               uniform non-porous surface for easy maintenance and hygiene.
              • Plate welded to the tube by invisible safety bead weld
               (process exclusive to "ArN-Securit").
              • 40mm gap between the bar and the wall:
               minimal space prevents the forearm passing between the bar
               and the wall, reducing the risk of fracture in case of loss of balance.
              • Concealed fixings, secured to wall by a 3-hole plate, Ø 72mm.
               Fixing plates and cover plates in 304 stainless steel.
              • Supplied with stainless steel screws for concrete walls.
              • Dimensions: 300 x 300mm, Ø 32mm.
              • Tested to over 200kg. Maximum recommended user weight: 135kg.
              • 10-year warranty.
              • CE marked.





                                                                                               8,5
                                                                                                    Ø 72
                                                                                           Ø 32
                                                                                                40





                                                                                           300
              Angled grab bar 90° Ø 32mm
                                                                                                300
              UltraPolish bright polished stainless steel  5180P2  £122.04
              UltraSatin polished satin stainless steel    5180S   £122.04
                                                                                              5180
              108 Accessibility - Stainless Steel Range
   105   106   107   108   109   110   111   112   113   114   115
