P. 115

Shower grab bars /


            L-shaped grab bar


                                                                                   Additional products












                                                                                                    Sliding shower head
                                                                                                    holder, sliding soap
                                                                                                    dish and shower shelf
                                                                                                    with glove holder
                                                                                                    (see page 121)


















                                                                                                  8,5
             UltraPolish
                                                                                                       Ø 72
                                                                                              Ø 32                        ACCESSIBILITY    STAINLESS STEEL
                                                                                                   40
              UltraSatin
                                                                                               5070/5071
            • For showers or baths.
            • Helps the user stand and move safely in the shower or bath.
            • Use as a shower rail by adding a sliding shower head holder and/or soap dish.
            • Bacteriostatic 304 stainless steel tube.
            • Stainless steel with UltraPolish bright polished finish or UltraSatin polished satin finish,
             uniform non-porous surface for easy maintenance and hygiene.
            • Plate welded to the tube by invisible safety bead weld (process exclusive to “ArN-Securit”).  750/1150
            • 40mm gap between the bar and the wall:
             minimal space prevents forearm passing between the bar
             and the wall, reducing the risk of fracture in case of loss of balance.
            • Concealed fixings, secured to wall by a 3-hole plate, Ø 72mm.
             Fixing plates and cover plates in 304 stainless steel.
            • Supplied with stainless steel screws for concrete walls.
            • Dimensions: 1,150 or 750 x 450mm, Ø 32mm.                                          450
            • Tested to over 200kg. Maximum recommended user weight: 135kg.
                                                                                                Left model
            • 10-year warranty.                                                               5070G/5071G
            • CE marked.



            L-shaped grab bar Ø 32mm - Height 750mm
            UltraPolish bright polished stainless steel - Left model  5070GP2  £184.60
            UltraPolish bright polished stainless steel - Right model  5070DP2  £184.60      750/1150
            UltraSatin polished satin stainless steel - Left model  5070GS  £184.60
            UltraSatin polished satin stainless steel - Right model  5070DS  £184.60
            L-shaped grab bar Ø 32mm - Height 1,150mm
            UltraPolish bright polished stainless steel - Left model  5071GP2  £208.66
            UltraPolish bright polished stainless steel - Right model  5071DP2  £208.66            450
            UltraSatin polished satin stainless steel - Left model  5071GS  £208.66
            UltraSatin polished satin stainless steel - Right model  5071DS  £208.66           Right model
                                                                                              5070D/5071D
                                                                                  Accessibility - Stainless Steel Range  113
