Page 117 - Accessibility-Accessories
P. 117

Shower grab bars /


            T-shaped grab bar


                                                                                   Additional products
























                                                                                   Sliding shower head holders, sliding soap dish
                                                                                   and shower shelf with glove holder (see page 121)











                                                                                                                          ACCESSIBILITY    STAINLESS STEEL
             UltraPolish

              UltraSatin


            • For showers.
            • Use as a grab bar and to support the user in an upright position.
            • Helps and secures entry and movement in the shower.
            • Use as a shower riser rail by adding a sliding shower head holder
             and/or soap dish.
            • Models with sliding riser rail: upright position can be adjusted
             during installation.
             Can be moved to the left or the right in order to adapt the space            8,5
             (positioning of shower, depth of shower seat...).
            • Bacteriostatic 304 stainless steel tube.                                         Ø 72
            • Stainless steel with UltraPolish bright polished finish                 Ø 32
             or UltraSatin polished satin finish, uniform non-porous surface               40
             for easy maintenance and hygiene.
            • Plate welded to the tube by invisible safety bead weld
             (process exclusive to "ArN-Securit").
            • 40mm gap between the bar and the wall:
             minimal space prevents the forearm passing between the bar
             and the wall, reducing the risk of fracture in case of loss of balance.
            • Concealed fixings, secured to wall by a 3-hole plate, Ø 72mm.
             Fixing plates and cover plates in 304 stainless steel.
            • Supplied with stainless steel screws for concrete walls.  Position of upright
            • Dimensions: 1,160 or 1,150 x 500mm, Ø 32mm.         can be adjusted (Ref. 5441)  1160     1150
            • Tested to over 200kg. Maximum recommended user weight: 135kg.
            • 10-year warranty. CE marked.

            T-shaped grab bar Ø 32mm with sliding vertical riser rail
            UltraPolish bright polished stainless steel           5441P    £294.63
            UltraSatin polished satin stainless steel             5441S    £294.63
            T-shaped grab bar Ø 32mm
            UltraPolish bright polished stainless steel          5440P2    £226.14       500            250   250
            UltraSatin polished satin stainless steel             5440S    £226.14
                                                                                         5441             5440
