Accessories for Commercial Kitchens /


        Swivelling spout                   ON/OFF waste                        HYGIÉNA waste
                                           Waste with stainless steel valve    Waste with concave grid












        • Swivelling spout.                • Washbasin waste M1¼" with stainless steel   • Hygienic washbasin waste M1¼".
        • F¾".                              valve with free flow.               • Concave grid (no water retention).
        • Chrome-plated brass.             • Recommended for all washbasins equipped    • Free flow, with no central screw
        • Models 966230 & 966380: can be mounted   with electronic or time flow mixers/taps    (reduces bacterial development).
         above or below a wall-mounted mixer.   and washbasins with overflow.   • Polished chrome-plated brass grid,
        • Flow straightener.               • Open/close by simply pressing      chrome-plated ABS body.
        • 10-year warranty.                 the top of the waste.              • Tall version: tightens to a min. 1mm or max.
                                           • 10-year warranty.                  45mm; pre-scored waste: (snap-off sections
                                                                                can be removed for basins with overflow).
                   3/4"                                                         Short version: tightens to a min. 1mm or max.
                                                                                2mm; special stainless steel washbasins.
                                                                               • Complies with EN 274 1. 10-year warranty.
                  135                                Ø 61                          Ø 63
                                                      Ø 42       30             1 - 45  Ø 39           Ø 63
                        200-290
                                                                 50                                        Ø 64
                                                      1"1/4                     50                 1-2        50
                      966230                                                           1"1/4      1"1/4
        Swivelling spout                                 581000                    611                6110
        Telescopic L. 200 - 290mm  966230                                      HYGIÉNA waste
        Telescopic L. 300 - 470mm  966380                                      Tall version               611
        Tubular L. 200mm        943200110   ON/OFF waste             581000    Short version             6110

        Nylon flexible hose                 Standard offset connectors          Copper tails
        For retracting hand sprays         M½" M¾" wall-mounted connectors     To supply mixers and taps













        • Nylon flexible hose L. 1.50m      • Chrome-plated connectors          • Soft-tempered copper tails.
         with counterweight for retracting hand spray    for wall-mounted mixers.   • Can be installed instead of PEX flexibles.
         (see ref. 2597 page 41).          •  M½" M¾".                         • Better conductors than flexibles.
        • Conical F½" union and cylindrical M15 1 union.  • Supplied in packs of 2.  • More effective for thermal shocks.
                                           • 10-year warranty.                 • Supplied in packs of 2.
                                                                               • 10-year warranty.
                  15x1
                                                     Ø 64        Ø 70
                                                 1/2"         1/2"             Pro tip: don’t forget to include non-return valves
                                                       3/4"
                                                                     3/4"      on the copper tubes if the PEX flexibles to be replaced
                                1/2"                                                                                  ADDITIONAL FITTINGS
                                                 11           12               have intergrated non-return valves.
                                                                               Contact our Technical team for further information.
                                                    50            35-41
                                                                  60
                                                                                               365
                                                 856794.2P     856027.2P
                                                                                    Ø 10                  11x1
             1,50 m                                                                         811611.2P
                                            Wall-mounted standard connectors
                        835T1               L.50, C C 11mm, Ø 64mm  856794.2P
                                            L.60, C C 12mm, Ø 70mm  856027.2P  Copper tails
                                            L.60, C C 21mm, Ø 70mm  857027.2P  M10   1 L. 365mm        811610.2P
        Nylon flexible hose L. 1,50m  835T1  L.50, C C 11mm, Ø 70mm  856127.2P  M11   1 L. 365mm        811611.2P


                                                                                             Additional fittings  79
