Page 83 - Professional_Catering
P. 83

Soap dispensers /


        Electronic soap dispenser          Liquid soap dispenser               Liquid soap dispenser
        Wall-mounted                       With soft-touch operation           ABS






















        • Vandal-resistant model           • Vandal-resistant model            • White ABS.
         with lock and standard DELABIE key.  with lock and standard DELABIE key.  • Push-button with non-drip system.
        • No manual contact: hands are automatically   • Cover made from bacteriostatic 304   • With lock.
         detected by infrared cell (detection distance   stainless steel.      • Level control.
         can be adjusted).                 • One-piece hinged cover for easy   • Capacity: 0.9 litre.
        • Cover made from bacteriostatic 304   maintenance and better hygiene.  • Dimensions: 95   130   235mm.
         stainless steel.                  • Push-button with soft-touch operation.  • 10-year warranty.
        • One-piece hinged cover           • Anti-blocking: single dose per press even
         for easy maintenance and better hygiene.  when the button is pressed for long periods.
        • No waste pump dispenser: dispenses 0.8ml   • No waste, non-drip (waterproof) pump-action
         (can be adjusted up to 7 doses per activation).  dispenser.
        • Option of operation in anti-clogging mode.  • Tank with large opening: easy to refill from
        • Power supply: 6 AA -1.5V (DC9V) batteries   large containers.
         supplied integrated in the soap dispenser body.  • Tank prevents long-term stagnation of soap.
        • Low battery indicator light.     • Window allows soap level to be checked.
        • Tank with large opening: easy to fill   • Capacity: 1 litre.
         from large containers.            • Stainless steel thickness: 1mm.
        • Window allows soap level to be checked.  • Dimensions: 90   105   252mm.
        • Capacity: 1 litre.               • For vegetable-based liquid soap
        • Stainless steel thickness: 1mm.   with a maximum viscosity of 3,000 mPa.s.
        • Dimensions: 90   105   256mm.    • Compatible with hydroalcoholic gel.
        • For vegetable-based liquid soap   • 10-year warranty.
         with a maximum viscosity of 3,000 mPa.s.
        • Compatible with hydroalcoholic gel.
        • 10-year warranty.
        • CE marked.





                                                               80
                                                                                          130       95


                        256                               252                          235
                                                                                                                      ADDITIONAL FITTINGS


                             79                                55
                                                                90
                 105         90                      105
                      512066                             510580                              374001






        Electronic liquid soap dispenser    Liquid soap dispenser
        Bright polished 304 stainless steel  512066P  Bright polished 304 stainless steel  510580
        Polished satin 304 stainless steel  512066S  Polished satin 304 stainless steel  510582
        White powder-coated 304 st. steel  512066W  White powder-coated 304 st. steel  510581  Hypereco liquid soap dispenser  374001


                                                                                             Additional fittings  81
   78   79   80   81   82   83   84   85   86   87   88
