/ Frame systems for direct flush

WHAT ARE THE ADVANTAGES OF A TEMPOFIX 3 FRAME SYSTEM?

Easy to install Optimised for stocking
Installation and commissioning time should be taken Reduced frame weight and product packaging save
into account when determining the total product cost, space for storage and are an advantage for being kept
especially when installing a large number of products on construction sites.
in public and commercial places.
Advantages of wall-hung WCs
The TEMPOFIX 3 frame system is delivered The height of the pan can be adjusted to suit
pre-mounted. The remaining components (flush tube,
Easy to clean housing and soil pipe) are assembled by clipping into the needs of the user, from children to people
place. It is quick and easy to install. with reduced mobility.
A wall-hung WC allows easy access to clean the floor
When fixing the self-supporting TEMPOFIX 3 version
400 KG below the WC pan.
of the frame system, the floor quality is the main criteria:
the concrete floor should withstand a minimum load Space saving
3
of 350kg/m .
On average the TEMPOFIX 3 takes up 30% less
It is possible to install on non-load bearing floors space than other frame systems on the market.
(parquet, floors with underfloor heating, etc.) thanks to It is one of the most compact frame systems.
the wall-mounted model which is fixed to load-bearing
walls. With no need for a cistern, it can be installed
DELABIE recommends a 25mm minimum wall thickness in the tightest of places such as service ducts.
Self-supporting TEMPOFIX 3
+ tiling (= 2 ½" wall boards or 1 1" wall board). The wall-anchoring bolts enable two TEMPOFIX 3
frames to be fixed back-to-back in a communal
Easy to adjust service duct (in Ladies and Gents toilets for example)
400 KG Adjusting the pan height is simple: a mark indicates without the need for a partition wall.
the "1-metre" point from the finished floor level on the
frame system. Products suited to the needs of healthcare
facilities
Vandal-resistant Increasingly in public places, plasterboard walls
The structure of DELABIE's frame system is made are being replaced by gypsum blocks, brick, or even
from powder-coated steel. Its design provides cinder blocks in order to improve the durability of
it with an unrivalled resistance to deformation. the installations.
Wall-mounted TEMPOFIX 3
The French standard NF D12 208 requires that frame The TEMPOFIX 3, equipped with a new recessed
systems flex no more than 5mm when subjected waterproof housing, functions electronically
to a uniformly distributed load of 400kg. (TEMPOMATIC dual control and Connect)
The TEMPOFIX 3 withstands 400kg loads or with timed flow (TEMPOFLUX 3), and the one model
and therefore meets this requirement.
can adjust to any type of wall finish from 10 - 120mm.
It is delivered with large stable feet (for self-supporting DELABIE has also developed its range of TEMPOFLUX 2
installation) or with wall fixings (for wall-mounted direct flush valves, offering extended versions of
installation).
the valves and frames so that they can be adjusted
All of DELABIE's flush system control plates are to thicker walls up to 130mm.
mounted to the supporting surface manually
TEMPOFIX 3 for thick walls (via concealed fixings). This gives greater durability Such an innovative installation would prove difficult
to achieve with cisterns.
and prevents unwanted removal.

TEMPOFIX 3 and its innovative waterproof housing,
ONE SINGLE PRODUCT for wall depths from 10 - 120mm
Drywalls (plasterboard): Semi-thick walls made Thick walls made from
Min. 10mm thick from gypsum blocks bricks or cinder blocks:
Max. 120mm thick

148 WCs / Frame systems
