Electronic direct flush systems TEMPOMATIC Connect /

TEMPOMATIC Connect TEMPOFIX 3 with TEMPOMATIC Connect
Recessed electronic WC flush system Frame system with electronic WC flush system

NEW NEW 186x186
3/4"

1000-1320

Ø 110
180-230
350
10-120
• Flush system without cistern: directly connected to pipework.
• Battery-operated with CR123 6V Lithium batteries or 230/6V mains
supply (cable and transformer supplied).
• Satin finish stainless steel control plate 186 186mm.
• Control plate fixed manually via concealed screws.
• Recessed waterproof housing:
- Collar with waterproof seal.
- Hydraulic connection from the outside and maintenance from the front.
- Adjusts to all types of installation (rails, solid walls, panels).
- Compatible with wall finishes 10 - 120mm.
- Suitable for standard or "pipe-in-pipe" supply.
- Stopcock and flow rate adjustment, and electronic activation unit are 300-620
all integrated and accessible from the front.
- TEMPOMATIC F¾" flush valve is compatible with sea water,
rain water and grey water. 165
- Vacuum breaker inside the housing. 157-177
- Supplied in 2 kits: secure system flush without sensitive elements. 564005DE + 465000
• Effective detection thanks to dual sensors (telemetric and infrared).
• Presence detection delay: 10 seconds. • Black powder-coated steel frame.
• Two activation modes: • Frame height can be adjusted from 0 - 200mm (with 1m mark).
- touch-free, by passing the hand in front of the sensor, • Waterproof housing.
- an automatic flush that is activated after each user leaves. • Ø 32mm flush tube with Ø 55mm connection washer.
• "Intelligent" automatic rinsing: flush volume adapts according • ABS soil pipe with HDPE sleeve connector, Ø 110mm outlet.
to use - 3L "short" usage, 6L "long" usage - (can be adjusted). With waterproof seal, with 2 setting positions.
• Hygienic duty flush every 24 hours (can be adjusted to 12 hours or OFF) • Delivered pre-mounted.
after the last use. • Compatible with solid walls from 10 to 120mm.
®
• Bluetooth configuration via the DELABIE Connect app (see pages 150 • 30-year warranty.
and 151) or manually set detection distance via the concealed button.
• Outlet connection for PVC tube Ø 26/32mm. Available in 2 versions:
• Supply pipe diameter: Ø 20mm minimum internal pipe diameter Self-supporting frame system with large feet to fix to load-bearing floors.
is required at all points (connectors included). Wall-mounted frame system to fix to load-bearing walls.
• Base flow rate: 1 L/sec at 1 bar dynamic pressure.
• Suitable for rimless WC pans and people with reduced mobility. Fitted with a TEMPOMATIC Connect F¾" electronic flush valve: BED PAN CLEANERS
• 30-year warranty. (see opposite). WCs - FRAMES
225 93-190
186x186
3/4"

150

Product currently under development.
TEMPOFIX 3 WC frame system with TEMPOMATIC Connect
464SBOX + 465000
564065DE £435.99
Self-supporting frame system - 6V battery-operated
+ 465006 £628.90
Product currently under development. 564005DE £435.99
Self-supporting frame system - 230/6V mains supply
TEMPOMATIC Connect WC recessed in a waterproof housing + 465000 £628.90
464PBOX £180.17 564060DE £390.10
6V battery-operated Wall-mounted frame system - 6V battery-operated
+ 465006 £628.90 + 465006 £628.90
464SBOX £180.17 564000DE £435.99
230/6V mains supply Wall-mounted frame system - 230/6V mains supply
+ 465000 £628.90 + 465000 £628.90
We recommend a flush tube (see page 170) Options: wall fixings, sleeve connector and kit for disabled WCs (see page 170)
WCs / Frame systems 153
