/ Electronic direct flush systems for WCs TEMPOMATIC dual control

TEMPOMATIC DUAL CONTROL RECESSED:
100% WATERPROOF RECESSED HOUSING, MODULAR AND ADAPTABLE

Modular 100% waterproof
DELABIE's recessed housing can be attached from the sides, front Standard housings on the market are designed to be cut to size flush
or back, to be fixed to plasterboard rails, load-bearing walls or even to the wall, which increases the risk of leaks between the wall
thin panels. The installation is therefore modular, and adapts to suit and the collar.
any project. DELABIE's recessed housing is equipped with a collar with
an integrated seal, that clips onto the housing once the wall finish is
in place (patented system). It is completely waterproof without the
need for silicone. Any condensation is evacuated via the plate. The
wall stays intact throughout.

Plasterboard rails Load-bearing walls Panels

Adaptable
The ideal positioning of the collar allows the housing to be cut to size
lengthwise depending on the wall thickness, whilst still guaranteeing
a complete waterproof seal. The housing adapts to all wall depth Collar with integrated waterproof seal
requirements, thick or thin, from 10 to 120mm.
Resistant to intensive use and vandalism
The control plate, made from satin stainless steel, will withstand
even the most extreme handling. Its fixings are concealed and its
streamlined design prevents unwanted removal. To prevent abuse or
waste in the voluntary mode, the TEMPOMATIC dual control
is fitted with an AB anti-blocking system. This security feature
prevents the valve from being blocked in the open position.
The flush takes place only when the push-button is released.

Minimal servicing and simple to maintain
Thick wall finish Narrow wall finish
Max. 120mm Min. 10mm Maintenance is carried out from the front by simply removing
the control plate. The technical elements are accessible
and the component parts come pre-assembled.
Quick and easy to install An LED indicates when the batteries need to be replaced. They
The TEMPOMATIC dual control can be connected to standard pipes are integrated into the control plate, they can be replaced without
or "pipe-in-pipe". shutting off the water supply or removing the valve.
The hydraulic connection is made from the outside of the housing. The vacuum breaker is located inside the housing.
During installation, the electronic unit is replaced by a temporary cap In case of backflow, the water will evacuate in front of the wall
to flush the system safely, without damaging the technical elements. via the housing, and not behind (or into) the wall.
The TEMPOMATIC dual control is compatible with sea water, rain
water and grey water.
Making protection from frost and in-depth maintenance easier,
the valve can be disconnected and removed from the inside,
Electronic unit
without removing the housing.
Hygiene
The TEMPOMATIC dual control flush can be activated voluntarily via
the push-button, or automatically once the user leaves. This ensures
Temporary cap
a rinse between each user, guaranteeing permanent hygiene for the
WC pan and improved cleanliness in public washrooms. The duty
flush prevents bacterial proliferation and ensures that the pipework
Water savings is flushed every 24 hours when not in use.
DELABIE has developed an "intelligent" rinse function
in the automatic mode. The system can distinguish between Design
the need for a short rinse (2 to 3 litres) or a longer flush (4 to 6 litres).
The TEMPOMATIC dual control plate has a timeless design,
available in satin finish stainless steel with a chrome-plated metal
push-button.
Thanks to its sleek lines, it fits perfectly in any type of public building.
Its smooth surface limits the build-up of dirt and facilitates cleaning.
