Electronic direct flush systems for WCs TEMPOMATIC /

TEMPOMATIC
Cross wall electronic flush valve

NEW

• Flush system without cistern: directly connected to pipework.
• Mains supply with 1" solenoid valve.
• 230/12V transformer.
• Independent IP44 electronic unit.
• Cross wall installation.
• Effective detection thanks to dual sensors (telemetric and infrared).
• Two activation modes:
- touch-free, by passing the hand in front of the sensor,
- an automatic flush that is activated after each user leaves.
®
• Bluetooth configuration via the DELABIE Connect app (see pages 150
and 151) or manually set detection distance via the concealed button. 1" 62
• "Intelligent" automatic rinsing: flush volume adapts according to use -
3L "short" usage, 6L "long" usage (can be adjusted).
• FF1" stopcock. 62
• Ø 32mm vacuum breaker. 265 0,5m
• Ø 32/55mm connection washer.
• Escutcheon flush to wall. Threaded rod can be cut to size. 0,1m
• Supply pipe diameter: Ø 20mm minimum internal pipe diameter is 115
required at all points (connectors included). Ø 29
• Base flow rate: 1 L/sec at 1 bar dynamic pressure. Ø 55 Ø 32 Ø 32 Ø 32 BED PAN CLEANERS
• Compatible with rainwater. 1,5m Ø 60 WCs - FRAMES
• Suitable for rimless WC pans and people with reduced mobility. 4m 30 max
• 30-year warranty.
464100

1" 62

62
265 0,5m
0,1m
115
200 max
Product currently under development. Ø 32
4m Ø 32 Ø 32
TEMPOMATIC WC cross wall flush valve Ø 32 Ø 55 Ø 21
For walls ≤ 30mm 464100 £803.61 1,5m Ø 60
For walls ≤ 200mm 464200 £815.44
Alternative cross wall lengths available on request
464200
WCs / Frame systems 159
