/ Time flow direct flush systems for WCs TEMPOFLUX 3

TEMPOFLUX 3 RECESSED:
100% WATERPROOF RECESSED HOUSING, MODULAR AND ADAPTABLE

Modular 100% waterproof
DELABIE's recessed housing can be attached from the sides, front Standard housings on the market are designed to be cut to size flush
or back, to be fixed to plasterboard rails, load-bearing walls or even to the wall, which increases the risk of leaks between the wall
thin panels. The installation is therefore modular, and adapts to suit and the collar.
any project. DELABIE's recessed housing is equipped with a collar with
an integrated seal, that clips onto the housing once the wall finish
is in place (patented system).
It is completely waterproof without silicone. Any condensation
is evacuated via the plate. The wall stays intact throughout.

Plasterboard rails Load-bearing walls Panels

Adaptable
The ideal positioning of the collar allows the housing to be cut to size
lengthwise depending on the wall thickness, whilst still guaranteeing Collar with integrated waterproof seal
a complete waterproof seal. The housing adapts to all wall depth
requirements, thick or thin, from 10 to 120mm.
Resistant to intensive use and vandalism
The control plate, made from satin finish stainless steel, will
withstand even the most extreme handling. Its fixings are concealed
and its streamlined design prevents unwanted removal. To prevent
abuse or waste, the TEMPOFLUX 3 is fitted with an AB anti-
blocking system. This security feature prevents the valve from being
blocked in the open position. The flush takes place only when the
push-button is released.
Minimal servicing and simple to maintain
Thick wall finish Narrow wall finish Maintenance is carried out from the front by simply removing
Max. 120mm Min. 10mm the control plate. The technical elements are accessible
and the component parts come pre-assembled.
The flush volume can be adjusted directly behind the control plate,
Quick and easy to install without shutting off the water supply or removing the valve.
The TEMPOFLUX 3 can be connected to standard pipes
or "pipe-in-pipe". The hydraulic connection is made from the outside The vacuum breaker is located inside the housing.
of the housing. In case of backflow, the water will evacuate in front of the wall
During installation, the cartridge is replaced by a temporary cap via the housing, and not behind (or into) the wall.
to flush the system safely, without damaging the technical elements. The TEMPOFLUX 3 is compatible with sea water, rain water and
grey water. Making protection from frost and in-depth maintenance
easier, the valve can be disconnected and removed from the
Cartridge inside, without removing the housing.

Comfort
Thanks to its soft-touch operation, the TEMPOFLUX 3 can be used
by all users (children, the elderly or people with reduced mobility).
The acoustic level is low and complies with European standard
Temporary cap EN 12541 class II.
Design
Water savings The TEMPOFLUX 3 control plate has a timeless design available
The TEMPOFLUX 3 with 3L/6L dual flush optimises flushing in 2 finishes: satin finish stainless steel or chrome-plated metal.
and water consumption. The flush volume can be adjusted to 2L/4L, Thanks to its sleek lines, it fits perfectly in any type of public building.
to achieve the highest standards for environmental labels. Its smooth surface limits the build-up of dirt and facilitates cleaning.
For more information see page 211.
The AB anti-blocking device limits the flush volume regardless
of how long the push-button is pressed for.

160 WCs / Frame systems
