/ Deck-mounted TEMPOMATIC MIX electronic controls

TEMPOMATIC MIX
Electronic mains or battery-operated mixer with swivelling spout

• Independent IP65 electronic control unit.
• 230/12V mains supply with transformer or CR123 6V Lithium batteries.
• BIOCLIP models supplied with 2 removable stainless steel spouts L. 183mm.
• Body and spout with smooth interiors (reduces bacterial development).
• Adjustable duty flush (pre-set flush ~60 seconds every 24 hours after last use).
• Flow rate limited to 5 lpm at 3 bar.
• Shock-resistant infrared presence detection sensor.
• Chrome-plated brass body with fixing reinforced by 2 stainless steel rods.
• Hygiene lever L. 100mm controls temperature.
• PEX flexibles with filters and solenoid valves M⅜".
• Anti-blocking security.
• Solenoid valves are upstream of the mixing chamber.
• Suitable for people with reduced mobility.
• 30-year warranty.

Two shut-off options on mains supply models:
Standard mode: timed flow with automatic shut-off.
ON/OFF mode: user shuts off flow voluntarily or automatic shut-off
after 30 minutes of flow.
Thermal shocks are possible.
Pro tip: in ON/OFF mode position the sensor on the side of the mixer.

183
160

110x75x40
35 max 2

430
TEMPOMATIC MIX mixer with swivelling spout
Quick and easy to install
Mains supply on BIOCLIP mixers:
BIOCLIP, H. 160mm L. 183mm 20870T1 £697.26 3/8"  Turn the stainless steel spout
H. 165mm L. 160mm 20164T1 £601.57 through 90º clockwise then
pull it towards you to remove it.
Battery-operated 2 Put another spout in its place.
H. 165mm L. 160mm 20464T1 £681.66
Options: wastes (see page 97), BIOFIL tap filters (see page 23),
stainless steel spouts or BIOFIL spout filters (see page 54)
20870T1
