Frame systems for direct flush /

WHAT ARE THE ADVANTAGES OF A TEMPOFIX 3 FRAME SYSTEM
IN PUBLIC AND COMMERCIAL PLACES?

Easy to install Advantages of wall-hung WCs
Installation and commissioning time should be taken The height of the pan can be adjusted to suit the needs
into account when determining the total product cost, of the user, from children to people with reduced
especially when installing a large number of products mobility.
in public and commercial places.
A wall-hung WC allows easy access to clean the floor
The TEMPOFIX 3 frame system is delivered below the WC pan. Easy to clean
pre-mounted. The remaining components (flush tube,
housing and soil pipe) are assembled by clipping into Space saving
place. It is quick and easy to install. On average the TEMPOFIX 3 takes up 30% less 400 KG
space than other frame systems on the market.
When fixing the self-supporting TEMPOFIX 3 version of It is one of the most compact frame systems.
the frame system, the floor quality is the main criteria:
the concrete floor should withstand a minimum load With no need for a cistern, it can be installed
of 350kg/m . in the tightest of places such as service ducts.
3
It is possible to install on non-load bearing floors The wall-anchoring bolts enable two TEMPOFIX 3
(parquet, floors with underfloor heating, etc.) thanks to frame systems to be fixed back-to-back in a
the wall-mounted model which is fixed to load-bearing communal service duct (in Ladies and Gents toilets
walls. for example) without the need for a partition wall. Self-supporting TEMPOFIX 3
DELABIE recommends a 25mm minimum wall thickness
+ tiling (= 2 ½" wall boards or 1 1" wall board). Products suited to the needs of public
and commercial places 400 KG
Increasingly in public and commercial places,
Easy to adjust
Adjusting the pan height is simple: plasterboard walls are being replaced by gypsum
a mark indicates the "1-metre" point from the finished blocks, brick, or even cinder blocks in order to improve
floor level on the frame system. the durability of the installations.
The TEMPOFIX 3, equipped with a new recessed
Vandal-resistant waterproof housing, functions electronically
The structure of DELABIE's frame system is made (TEMPOMATIC dual control and Connect) or with
from powder-coated steel. Its design provides it timed flow (TEMPOFLUX 3), and one model can
with an unrivalled resistance to deformation. adjust to any type of wall finish from 10 - 120mm. Wall-mounted TEMPOFIX 3
The French standard NF D12 208 requires that frame DELABIE has developed its range of TEMPOFLUX 2
systems flex no more than 5mm when subjected direct flush valves, offering extended versions of
to a uniformly distributed load of 400kg. the valves and frames so that they can be adjusted
The TEMPOFIX 3 withstands 400kg loads to thicker walls up to 130mm.
and therefore meets this requirement.
Such an innovative installation would prove difficult
It is delivered with large stable feet (for self-supporting to achieve with cisterns.
installation) or with wall fixings (for wall-mounted
installation). All of DELABIE's flush system control
plates and wall plates are mounted to the supporting
surface manually (via concealed fixings).
This gives greater durability and prevents unwanted TEMPOFIX 3 for thick walls CISTERN-LESS
removal. WCs

Optimised for stocking
Reduced frame weight and product packaging save
space for storage and are an advantage for being kept
on construction sites.
TEMPOFIX 3 and its innovative waterproof housing,
ONE SINGLE PRODUCT for wall depths of 10 - 120mm

Dry walls Semi-thick walls made Thick walls made from
(plasterboard): from gypsum blocks: bricks or cinder blocks:
Min. 10mm thick. Max. 120mm thick.

Cistern-less WCs 201
