TEMPOMATIC dual control electronic direct flush systems /

• Efficiency and water savings: direct flush reduces the risk of leaks, powerful flush is available instantly
• Hygiene: automatic flush, no cistern: no water stagnation (reduces bacterial development)
• Comfort: voluntary activation (push-button) or automatic flush (without contact)
• Easy to install: modular and adjustable waterproof housing (for walls and finishes)

TEMPOMATIC dual control
Recessed electronic direct flush valve

NEW

• Flush system without cistern: directly connected to pipework.
• Battery-operated with CR123 6V Lithium batteries
or 230/6V mains supply (cable and transformer supplied).
• Satin finish stainless steel or matte black control plate 186 186mm
and chrome-plated metal button with integrated electronics.
• Control plate fixed manually via concealed screws.
225 93-190
• Recessed waterproof housing: 186x186
- Collar with waterproof seal. 3/4"
- Hydraulic connection from the outside and maintenance from the front.
- Adjusts to all types of installation (rails, solid walls, panels).
- Compatible with wall finishes 10 - 120mm CISTERN-LESS
(while maintaining the minimum recessing depth of 93mm). 150 WCs
- Suitable for standard or "pipe-in-pipe" supply.
- Stopcock and flow rate adjustment, activation and electronic unit
are all integrated and accessible from the front.
- TEMPOMATIC F¾" flush valve is compatible with sea water, rain water 464PBOX + 464006
and grey water.
- Vacuum breaker inside the housing.
- Supplied in 2 kits: secure system flush without sensitive elements.
• Shock-resistant infrared presence detection sensor.
• Presence detection delay: 10 seconds.
• Two activation modes:
- Touch-free: the flush operates automatically after each user leaves,
Awards:
ensuring the bowl is rinsed between each user.
- By pressing on the anti-blocking push-button. *Product currently under development.
The flush will activate even if the power supply fails. TEMPOMATIC recessed WC dual control flush valve in a waterproof housing
• "Intelligent" automatic rinsing: flush volume adapts according to use Satin finish stainless steel control plate
- 3L "short" usage, 6L "long" usage - (can be adjusted to 2L/4L or 5L/9L). 464PBOX £180.17
• 3 programmes (rinse volume can be set according to type of WC pan). 6V battery-operated + 464006 £570.55
• Hygienic duty flush, every 24 hours (can be adjusted to 12 hours or OFF) 464SBOX £180.17
after the last use. 230/6V mains supply + 464000 £600.59
• Outlet connection for PVC tube Ø 26/32mm. Matte black stainless steel control plate
• Supply pipe diameter: Ø 20mm minimum internal pipe diameter
is required at all points (connectors included). 6V battery-operated 464PBOX £180.17
+ 464056* £600.09
• Base flow rate: 1 L/sec. at 1 bar dynamic pressure.
464SBOX
£180.17
• Suitable for rimless WC pans. 230/6V mains supply + 464050* £630.13
• Suitable for people with reduced mobility.
• 30-year warranty. We recommend a flush tube (see page 232)
Cistern-less WCs 203
