/ TEMPOMATIC dual control electronic direct flush systems

TEMPOMATIC DUAL CONTROL RECESSED:
100% WATERPROOF RECESSED HOUSING, MODULAR AND ADAPTABLE

Modular 100% waterproof
DELABIE's recessed housing can be attached from the sides, front Standard housings on the market are designed to be cut to size flush
or back, to be fixed to plasterboard rails, load-bearing walls or even to the wall, which increases the risk of leaks between the wall
thin panels. The installation is therefore modular, and adapts to suit and the collar.
any project. DELABIE's recessed housing is equipped with a collar with an
integrated seal, that clips onto the housing once the wall finish
is in place (patented system). It is completely waterproof
without silicone. Any condensation is evacuated via the plate.
The wall stays intact throughout.

Plasterboard rails Solid walls Panels
Adaptable
The ideal positioning of the collar allows the housing to be cut to size
lengthwise depending on the wall thickness, whilst still guaranteeing Collar with integrated waterproof seal
a complete waterproof seal. The housing adapts to all wall depth
requirements, thick or thin, from 10 to 120mm. Resistant to intensive use and vandalism
The control plate, made from stainless steel (in a satin or matte black
finish) will withstand even the most extreme handling. Its fixings are
concealed and its streamlined design prevents unwanted removal.
To prevent abuse or waste in the voluntary mode, the TEMPOMATIC
dual control is fitted with an AB anti-blocking system. This security
feature prevents the valve from being blocked in the open position.
The flush takes place only when the push-button is released.

Minimal servicing and simple to maintain
Maintenance is carried out from the front by simply removing
Thick wall finish Narrow wall finish the control plate. The technical elements are accessible
Max. 120mm Min. 10mm and the component parts come pre-assembled.
An LED indicates when the batteries need to be replaced.
Quick and easy to install They are integrated into the control plate, and can be replaced
The TEMPOMATIC dual control can be connected to standard without shutting off the water supply or removing the valve.
pipework or "pipe in pipe". The vacuum breaker is located inside the housing.
The hydraulic connection is made from the outside of the housing. In case of backflow, the water will evacuate in front of the wall
During the installation, the electronic unit is replaced by a temporary via the housing, and not behind (or into) the wall.
cap to flush the system safely, without damaging the technical The TEMPOMATIC dual control is compatible with sea water,
elements. rain water and grey water.
Making protection from frost and in-depth maintenance easier,
the valve can be disconnected and removed from the inside,
without removing the housing.
Electronic unit
Hygiene
The TEMPOMATIC dual control flush can be activated voluntarily via
the push-button, or automatically once the user leaves. This ensures
a rinse between each user, guaranteeing permanent hygiene for the
Temporary cap WC pan and improved cleanliness in public washrooms. The duty
flush prevents bacterial proliferation and ensures that the pipework
is flushed every 24 hours when not in use.

Water savings Design
DELABIE has developed an "intelligent" rinse function The TEMPOMATIC dual control plate has a timeless design, available
in the automatic mode. The system can distinguish between in satin finish stainless steel or matte black, with a chrome-plated
the need for a short rinse (2 to 3 litres) or a longer flush (4 to 6 litres). metal push-button. Thanks to its sleek lines, it fits perfectly in any
type of public and commercial building. Its smooth surface limits
the build-up of dirt and facilitates cleaning.

206 Cistern-less WCs
