TEMPOMATIC Connect electronic direct flush systems /

• Efficiency and water savings: direct flush system minimises the risk of leaks, powerful flush is available instantly
• Hygiene: touch-free electronic flush, no cistern: no water stagnation (reduces bacterial development)
• Comfort: contactless activation is voluntary by passing hand before sensor, or automatic when user leaves
• Easy to install: modular and adjustable waterproof housing for quick installation, or pre-mounted to frame system

TEMPOMATIC Connect
Recessed electronic flush valve

NEW

• Flush system without cistern:
directly connected to pipework.
• Battery-operated with CR123 6V Lithium batteries or 230/6V mains
supply (cable and transformer supplied).
• Satin finish or matte black stainless steel control plate 186
186mm.
• Control plate fixed manually via concealed screws.
• Recessed waterproof housing:
- Collar with waterproof seal.
225 93-190
- Hydraulic connection from the outside and maintenance from the front. 186x186
- Adjusts to all types of installation (rails, solid walls, panels). 3/4" CISTERN-LESS
- Compatible with wall finishes 10 - 120mm. WCs
- Suitable for standard or "pipe-in-pipe" supply.
- Stopcock, flow rate adjustment, activation and electronic unit are 150
integrated and accessible from the front.
- TEMPOMATIC F¾" flush valve is compatible with sea water, rain water
and grey water.
• Vacuum breaker inside the housing.
- Supplied in 2 kits: secure system flush without sensitive elements. 464SBOX + 465000
• Effective detection thanks to dual sensors
(telemetric and infrared).
• Presence detection delay: 10 seconds.
• Two activation modes:
- touch-free, by passing the hand in front of the sensor,
- an automatic flush that is activated after each user leaves. Product currently under development.
• "Intelligent" automatic rinsing: flush volume adapts according to use TEMPOMATIC Connect WC recessed in waterproof housing
- 3L "short" usage, 6L "long" usage - (can be adjusted). Satin finish stainless steel control plate
• Hygienic duty flush, every 24 hours (can be adjusted to 12 hours or OFF) 464PBOX £180.17
after the last use. 6V battery-operated + 465006 £628.90
®
• Bluetooth configuration via the DELABIE Connect app 464SBOX £180.17
(see pages 208 and 209) or manually set detection distance 230/6V mains supply + 465000 £628.90
via the concealed button. Matte black stainless steel control plate
• Outlet connection for PVC tube Ø 26/32mm.
• Supply pipe diameter: Ø 20mm minimum internal pipe diameter 6V battery-operated 464PBOX £180.17
+ 465056 £658.44
is required at all points (connectors included).
464SBOX
£180.17
• Base flow rate: 1 L/sec at 1 bar dynamic pressure. 230/6V mains supply + 465050 £658.44
• Suitable for rimless WC pans and people with reduced mobility.
• 30-year warranty. We recommend a flush tube (see page 232)
Cistern-less WCs 211
