Mirror cabinet with 3 or 4 functions /

• Design: 304 stainless steel cabinet with matte black finish
• Hygiene: no manual contact
• Comfort: 3 or 4 functions in one place

Mirror cabinet with 3 or 4 functions

• Mirror cabinet with 3 or 4 functions: mirror, electronic BASINS
NEW soap dispenser, electronic tap (included in 4 function
models) and hand dryer or paper towel dispenser.
• Designer cabinet in 304 stainless steel with matte black
melamine finish.
• Touch-free for improved hygiene:
soap dispenser, tap and hand dryer are automatically
activated when hands are detected by infrared sensor.
• Quick and easy to install:
- A single electrical connection for all the elements:
230V / 50 60Hz mains supply via transformer.
- Connects to the water supply from the top or from inside
the cabinet.
- M⅜" water connection.
- Concealed fixings: supplied with stainless steel screws
for concrete walls or reinforced wood.
- Adjustable hinges.
• Glass mirror and black glass strip with illuminated
pictograms.
• Electronic soap dispenser:
- No-waste pump dispenser.
- Large capacity tank: 5 litres.
- Suitable for plant-based liquid soap with a maximum
viscosity of 3,000 mPa.s or specific foam soap.
• Electronic basin tap (included in 4 function models):
- Reduced stagnation solenoid valve.
600 223 - Flow rate pre-set at 3 lpm at 3 bar, adjusts from 1.4
to 6 lpm.
- Scale-resistant flow straightener.
- Duty flush (~60 seconds every 24 hours after last use).
- Stopcock.
• Models with air pulse hand dryer :
- High speed dryer.
1000 - Pulsed air at 360 km/h. Airflow: 36 l/second.
- Low energy consumption: 704W.
- Noise level: 74 dBA.
- Class I, IP23. CE marked.
- 3-year warranty.
• Models with paper towel dispenser:
- Dispenses one sheet at a time.
190 190 172
- Dimensions: 120 × 275 × 360mm.
510203 - Capacity: 500 sheets.
Awards: • LED strip downlights for the basin.
Mirror cabinet with 4 functions • Vandal-resistant model with lock and standard
With hand dryer DELABIE key.
• Anti-blocking: stops water automatically if continuous
Width 600 mm 510203 £2,117.45
use is attempted.
Width 800 mm 510204 £2,488.29 • Internal storage shelf.
With paper towel dispenser • Several cabinets can be installed side-by-side to create
Width 600 mm 510205 £1,830.32 a mirror wall: linking screws are provided.
Width 800 mm 510206 £2,195.19 • CE marked.
• 30-year warranty (3-year for the hand dryers).
Mirror cabinet with 3 functions - for deck or wall-mounted water controls
With hand dryer
Width 600 mm 510207 £1,757.91
Width 800 mm 510208 £1,964.72
With paper towel dispenser
Width 600 mm 510209 £1,468.37
Width 800 mm 510210 £1,664.85
TMV for models with taps
PREMIX NANO tmv F1/2" - Ø 15mm 732115MEC £112.19
for compression fittings + connector + 808012 £7.39

Basins 27
