P. 67

DOC M WC Packs /


            Be-Line  WC pack with backrest     Be-Line WC pack                     Ambulant WC pack Be-Line   ®
                                                       ®
                    ®

















                                                                                                                          DOC M RANGE





                                    DOC M                              DOC M                               DOC M
                                    compliant                          compliant                           compliant
            • 1 backrest, depth 150mm          • 1 drop-down support rail, length 850mm.  • 3 grab bars, length 600mm.
             (ref. 511928C or 511928W).        • 4 grab bars, length 600mm.        • Aluminium tube Ø 35mm.
            • 1 drop-down support rail, length 850mm.  • Aluminium tube.           • Choice of powder-coated metallised
            • 4 grab bars, length 600mm.       • Choice of powder-coated metallised   anthracite (LRV 14) or matte white (LRV 82)
            • Aluminium tube.                    anthracite (LRV 14) or matte white (LRV 82)   finish; provides a good visual contrast
            • Choice of powder-coated metallised   finish; provides a good visual contrast   with the wall.
             anthracite (LRV 14) or matte white (LRV 82)   with the wall.          • Tested to over 200kg.
             finish; provides a good visual contrast   • Tested to over 200kg.     • Maximum recommended user weight: 135kg.
             with the wall.                    • Maximum recommended user weight: 135kg.  • 10-year warranty.
            • Tested to over 200kg.            • 10-year warranty.                 • CE marked.
            • Maximum recommended user weight: 135kg.  • CE marked.                • DOC M compliant.
            • 10-year warranty.                • DOC M compliant.
            • CE marked.
            • DOC M compliant.


                        513          150


                        400


                Ø 35             713               Ø  35            713
                 60                                60
                                 600                                600






             920                                920
                       120          850                  120           850
                                                                                      Ø 35             713
                     202                                202                           60
                               23     Ø  42                       23     Ø  42                         600
                109                                109
                          511809M                            511804M                            511811M


                      ®
                                                          ®
                                                                                                    ®
            DOC M Be-Line  WC pack with backrest  DOC M Be-Line  WC pack           DOC M ambulant Be-Line  WC pack
            Metallised anthracite               Metallised anthracite              Metallised anthracite
            powder-coated    511809MC  £989.51  powder-coated    511804MC  £791.38  powder-coated   511811MC  £330.23
            aluminium                           aluminium                          aluminium
            Matte white                         Matte white                        Matte white
            powder-coated    511809MW  £989.51  powder-coated    511804MW  £791.38  powder-coated   511811MW  £330.23
            aluminium                           aluminium                          aluminium
                                                                                                    DOC M range   65
