Non-contact controls Spouts /
Fixed spout Fixed L-shaped spout Fixed spout
Wall-mounted/Cross wall Wall-mounted Cross wall
• Spout Ø 32mm, M½". • Tubular spout Ø 18mm, M½". • Spout L. 75mm, M½".
• Chrome-plated solid brass. • L. 120mm. • For cross wall installation with anti-rotating
• Scale-resistant flow straightener regulated • Chrome-plated brass. pin.
at 3 lpm. • Flow straightener. • Threaded rod can be cut to size.
• 10-year warranty. • 10-year warranty. • Streamlined, ligature-resistant design.
• Chrome-plated solid brass.
Ø 32 Ø 60 Ø 21 1/2" • Star-shaped, scale-resistant flow straightener.
• 10-year warranty.
120 165 max
10 max
1/2"
Ø 48 Ø 21 1/2"
947151
60
120
Cross wall spout with wall plate 75 30 max
L. 120mm 947151
941922 942040
L. 170mm 947157
Wall-mtd spout, no wall plate (recessed inlet) NON-CONTACT CONTROLS
L. 110mm 947120 Wall-mounted fixed L-shaped spout Cross wall fixed spout
L. 160mm 947170 Star-shaped flow straightener 941120 For walls ≤ 30mm 942040
Wall-mtd spout with wall plate (recessed inlet) Flow straightener regulated at 3 lpm Back-nut with 3 screws 826315
L. 120mm 947135 for panels ≤ 10mm 941922 Alternative cross wall lengths available on request
Tubular spout Fixed or swivelling spout Hygienic flow straightener
Deck-mounted Deck-mounted
• Tubular spout on M½" base. • Spout M½". • Flow straightener with no grid reduces bacterial
• Chrome-plated brass. • Fixed via back-nut on models 967152 & 967202, development (no water or dirt retention).
• Spout with smooth interior reinforced fixing via 3 stainless steel screws • Models 922024.2P & 922022.2P:
(reduces bacterial development). on model 981142. scale-resistant flow straightener pre-set
• Scale-resistant flow straightener. • Chrome-plated brass. at 3 lpm (DELABIE patented).
• 10-year warranty. • Scale-resistant flow straightener regulated Flow rate can be adjusted from 1.4 - 6 lpm
at 3 l/min. at 3 bar (depends on mixer/tap model)
• 10-year warranty. from the outside using a 2.5mm Allen key.
• 10-year warranty.
150
22/100
170 24/100
140
150 120 120 15 17
1/2"
1/2" 150 922024.2P 921022.50P
25 max 15 max 1/2" 30 max 1/2" 30 max Scale-resistant flow straightener
1306T1 204001 140 M24/100 (2 per pack) 922024.2P
967152 981142
Swivelling tubular spout Ø 22mm F22/100 (2 per pack) 922022.2P
L. 150mm H. 140mm, 3 lpm 1306T1 Swivelling swan neck spout F22/100 (2 per pack) 921022.2P
L. 200mm H. 260mm, 3 lpm 1306T2 L. 150mm H. 120mm 967152 F22/100 (50 per pack) 921022.50P
L. 300mm H. 260mm 1306T3 L. 200mm H. 200mm 967202 M24/100 (2 per pack) 921024.2P
Fixed tubular spout Ø 16mm 204001 Fixed, cast spout 981142 M24/100 (50 per pack) 921024.50P
