/ Non-contact controls Foot or knee-operated


          TEMPOGENOU                                           MIXFOOT/MONOFOOT
          Knee-operated time flow basin valve                   Foot-operated basin mixer with instant shut-off






















          • Time flow ~7 seconds.                               • Instant automatic shut-off.
          • Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.  • Pedal can be raised for cleaning the floor.
          • Reinforced control lever.                          • Adjustable pedal height.
          • Solid brass wall plate with reinforced fixing via 4 stainless steel screws   • Fixed by 4 screws.
           on the in-line model.                               • Filters.
          • Cold or mixed water supply.                        • Pre-set mixing can be adjusted on the MIXFOOT mixer version:
          • Chrome-plated solid brass body, M½”.                half-open for cold water and fully open for mixed water
          • 10-year warranty.                                   (pedal touching the floor).
                                                               • Available for floor or wall-mounting.
                                                               • 10-year warranty.






                                       30
                                    1/2"                                                      1/2"
                                            Ø 80
                                                                                       280
                                    1/2"
                                435
                                735400                                                739100


                                      Ø 15
                                             37
                                                                                           1/2"
                                               Ø 70
                                      Ø 15
                                 440                                                   300
                                73544715                                              736102



                                        35
                                    1/2"
                                            Ø 50
                                 440       1/2"
                                 734100
                                                               MIXFOOT mixer
                                                               Floor-mounted, M½"                         739100
          TEMPOGENOU valve                                     Wall-mounted, M½"                          739102
          Straight for in-line inlet, stud nut       735000    MONOFOOT valve
          Straight for in-line inlet, M½”            735400    Floor-mounted, stud nut Ø 14mm             736001
          Straight for in-line inlet Ø 15mm compression fittings   73544715  Floor-mounted, M½"            736101
          Angled for recessed inlet, M½”             734100    Wall-mounted, M½"                          736102
          We recommend installing a TMV (see page 86)          We recommend installing a TMV (see page 86) with the MONOFOOT valve
          Option: spouts (see opposite)                        Option: spouts (see opposite)


          62  Non-contact controls
