/ Electronic controls TEMPOMATIC 4 wall-mounted

TEMPOMATIC 4
Electronic mixer or tap, battery or mains operated
• 230/12V mains supply or integrated CR123 6V Lithium
batteries.
• Reduced-stagnation solenoid valve and electronic unit
integrated into the body of the mixer/tap.
• Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from
1.4 - 6 lpm.
• Scale-resistant flow straightener.
• Duty flush (~60 seconds every 24 hours after last use).
• Active, infrared presence detection, sensor at the end of the
spout optimises detection.
• Chrome-plated stainless steel body.
• Cap fixed in place by 2 concealed screws.
• Stopcocks.
• Anti-blocking security.
• Side temperature control with adjustable maximum
temperature limiter on the mixers.
• Recommended installation height: 110 200mm above the
top of the basin.
• 10-year warranty.

Standard lever Long lever

100
1/2"
160
35 max 50x50x25

TEMPOMATIC MIX 4 wall-mounted mixer
Recessed mains supply
Wall-mounted L. 160mm (recessed water inlets) 493400
Wall-mounted L. 220mm (recessed water inlets) 493500 493400
Cross wall L. 190mm 493510
Battery-operated
Wall-mounted L. 160mm (recessed water inlets) 493406
Wall-mounted L. 220mm (recessed water inlets) 493506
Cross wall L. 190mm 493516
190 110
TEMPOMATIC 4 wall-mounted tap
Recessed mains supply
Wall-mounted L. 130mm (recessed water inlet) 443400
Wall-mounted L. 190mm (recessed water inlet) 443500 3/8"
493516
Cross wall L. 130mm 443410
Cross wall L. 190mm 443510
Battery-operated
Wall-mounted L. 130mm (recessed water inlet) 443406 165
3/8" 1/2"
Wall-mounted L. 190mm (recessed water inlet) 443506
Cross wall L. 130mm 443416
1/2"
Cross wall L. 190mm 443516 130 190 30 max
50x50x25
L. 130mm for panels ≤ 24mm 443426
L. 190mm for panels ≤ 24mm 443526
L. 130mm for refurbishment 443436
L. 190mm for refurbishment 443536
We recommend installing a TMV for taps (see page 86)
443410 443506

58 Non-contact controls
