P. 94

/ Spare parts Electronic controls & Thermostatic mixing valves


                                         SOLENOID VALVES

                                         For washbasins
                                         12V MM½" for TEMPOMATIC washbasins                           495626   A
                                         12V MM⅜" for TEMPOMATIC 2 & BINOPTIC washbasins              495612   A
                                         6V for TEMPOMATIC (MIX) 3 washbasins                         479651   -
                      A             B
                                         6V for TEMPOMATIC (MIX) 4 washbasins                         479748   B
                                         6V for TEMPOMATIC (MIX) 4 washbasins (with adjustable flow rate)  479650  -
                                         6V MM⅜" for TEMPOMATIC (MIX) 2, BINOPTIC (MIX)               495606   -


                                         ELECTRONIC CONTROL UNITS
                      C             D
                                         For washbasins
                                         230/12V standard with "duty flush" option, with transformer for washbasins  495444BC  C
                                         6V with integrated battery for TEMPOMATIC (MIX) 3 washbasins  492446  D
                                         6V with integrated battery for TEMPOMATIC (MIX) 4 washbasins  490446  E
                                         230/12V multifunction with transformer for washbasins       495445BC  C
                                         6V battery-operated for washbasins                          495446BC  C
                      E              F
                                         6V TEMPOMATIC (MIX) 4 washbasins mains supply                490450   E

                                         POWER SUPPLIES

                                         For washbasins
                                         6V, recessed                                                 490240   F
                      G             H
                                         6V, plug-in mains supply, UK model                          490241UK  G
                                         Extension                                                   490230EXT  -


                                         SENSORS
                                         For washbasins (the same model for washbasins, mains supply or battery-operated)
                      I              J
                                         With cable 0.10m                                             495009   H
                                         With cable 0.70m                                             495070   H
                                         With cable 1.50m                                             495149   H
                                         With cable 5.00m                                             495499   H
                                         For washbasins: BINOPTIC (MIX) and TEMPOMATIC (MIX) 2, cable 0.70m  CEL378V  -
                                         For washbasins: BINOPTIC (MIX) and TEMPOMATIC (MIX) 2, cable 1.50m  CEL378150V  -
                      K              L   For washbasins: BINOPTIC (MIX) and TEMPOMATIC (MIX) 2, cable 5.00m  CEL378499V  -
                                         NB: cable can not be extended or cut

                                         BATTERIES

                                         For washbasins
                                         2   3V 123/CR – 17345 Lithium batteries                      990123   I
                                         1   6V 223/CR – P2 Lithium battery                           990223   J



                                         THERMOSTATIC MIXING VALVES

                                         Repair kits                                                 Repair kit  Type
                                         For PREMIX COMPACT
                                         Ref.s 733015, 733016, 733020, 733021 (old design)            753733   K
                                         Ref.s 733015, 733020 (new design)                            753734   -
                                         For PREMIX NANO
                                         Ref.s 732012, 732016, 732115, 732116, 732216                 743732   L












          92  Spare parts
