P. 92

/ Spare Parts Spout outlets, spouts, hand sprays


                                         SPOUT OUTLETS

                                         Scale-resistant aerators with brass collar
                                         F22/100 (5 per pack)                                          22.5P   A
                                         M24/100 (5 per pack)                                          24.5P   B
                                         M28/100 (2 per pack)                                          28.2P   -
                      A             B
                                         Scale-resistant and tamperproof aerators with eco washer
                                         F22/100 (2 per pack)                                        925622.2P  A
                                         M24/100 (2 per pack)                                        925624.2P  B
                                         BIOSAFE outlets (free flow outlets with no grid or partitions in contact with the water) with brass collar
                                         F22/100 (1 per pack) for basin taps / mixers 5 lpm           923022   -
                                         F22/100 (50 per pack) for basin taps / mixers 5 lpm         923022.50P  -
                      C             D    M24/100 (1 per pack) for basin taps / mixers 5 lpm           923024   C
                                         M24/100 (50 per pack) for basin taps / mixers 5 lpm         923024.50P  C
                                         Hygienic flow straighteners (star-shaped with no grid: reduces bacterial development) with brass collar
                                         F22/100 (2 per pack)                                        921022.2P  -
                                         F22/100 (50 per pack)                                       921022.50P  -
                                         M24/100 (2 per pack)                                        921024.2P  D
                      E             F    M24/100 (50 per pack)                                       921024.50P  D
                                         Flow straighteners at 3 lpm (flow rate can be adjusted via 2.5mm Allen key) with brass collar
                                         F22/100 (2 per pack)                                        922022.2P  E
                                         M24/100 (2 per pack)                                        922024.2P  -
                                         Adjustment key (2.5mm Allen key)                             C282025  F
                                         Filters flat washer filter in Nylon, 0.5mm mesh
                                         For ½" nut (10 per pack)                                    60212.10P  G
                      G
                                         For ¾" nut (10 per pack)                                    60234.10P  G
                                         Connectors
                                         2 connectors with non-return valves, FM⅜"                   C151AH75  -
                                         2 connectors with non-return valves, FM½"                   C291AH75  -
                                         SPOUTS
                300
                               300
                                         Spouts L. 300mm
                                         Over spout Ø 22mm, H. 235mm
                      230
                                    130  with ¾" nut and star-shaped brass flow straightener         963300245G  -
          3/4"           3/4"            Over spout Ø 22mm, H. 230mm
                      H              I
                                         with ¾" nut and star-shaped flow straightener               963300245F  H
                200
                                         Over spout Ø 22mm, H. 130mm
                               200       with ¾" nut and star-shaped flow straightener               963300145F  I
                                         Spouts L. 200mm
                    230                  Over spout Ø 22mm, H. 230mm
                                  135
                                         with ¾" nut and flow straightener regulated at 3 lpm       963200245F  J
            3/4"           3/4"
                      J             K    Over spout Ø 22mm, H. 135mm
                                         with ¾" nut and star-shaped flow straightener               963200145F  K
                               150       Under spout Ø 22mm, H. 117mm
              3/4"
                                         with ¾" nut and star-shaped brass flow straightener          943200110  L
                                  105    Spout L. 150mm
                200
                           3/4"          Over spout Ø 22mm, H. 105mm
                      L             M    with ¾" nut and flow straightener regulated at 3 lpm        963150125F  M
                                         Over spout Ø 22mm, H. 100mm
                                         with ¾" nut and BIOSAFE outlet                             963150923F  -
             3/4"
                                         Universal telescopic spouts
            135                          Spout L. 200 - 290mm
                                         with ¾" nut and star-shaped flow straightener                 966230   N
                200-290
                                         Spout L. 300 - 470mm
                      N
                                         with ¾" nut and star-shaped flow straightener                 966380   -
                                         HAND SPRAYS

                                         For pre-rinse sets                                          Repair kit  Type
                                         Nozzle for white hand spray 433000                           433305   -
                                         Nozzle for black hand spray 433010                           433315   -




          90  Spare parts
