Spare parts Pre-rinse sets and Commercial Kitchen controls /


        CONTROL KNOBS

        Valve heads                                                  Repair kit  Type
        Complete valve head - ¼-turn right CW (Ø 22   150mm) + control lever
        Ref.s 433622, 433722, 435622, 435722, 5630, 5632, 5633, 5633UK, 5634, 5636, 5640T2,
        5640T3, 5641T2, 5641T2UK, 5641T3, 5641T3UK, 5645T2, 5647T2, 5647T3, 5680, 5680UK,   P272AA85  A  A    B
        5830, 5832, 5833, 5834, 5836, 5880
        Complete valve head - ¼-turn left HW (Ø 22   150mm) + control lever
        Ref.s 5630, 5632, 5633, 5633UK, 5634, 5636, 5640T2, 5640T3, 5641T2, 5641T2UK, 5641T3,   P271AA85  A
        5641T3UK, 5645T2, 5647T2, 5647T3, 5680, 5680UK, 5830, 5832, 5833, 5834, 5836, 5880
        Complete valve head - ½-turn right CW (Ø 28   150mm) + control lever
        Ref.s 5603, 5610, 5612                                      P296AA85  B
        Complete valve head - ½-turn left HW (Ø 28   150mm) + control lever                     C             D
        Ref.s 5603, 5610, 5612                                      P295AA85  B
        Valve head without control knob  (2 pieces)
        Ref.s 433220, 433422, 435220, 435422, D2553, G6432, G6433, G6532, G6533, G65602, G65603,   366015.2P  C
        G6632, G6633, G66452, G66453, G6679, G6732, G6733, G6832, G6833, G6932, G6933
        Ceramic valve head + control knob
        Ref. 5445T2S                                                  P5445   -
        Ceramic valve head ½", ¼-turn right                                                     E             F
        Ref. 5675T2 (before 12/2017), D275059                       P482AJ75  D
        CARTRIDGES

        For mixers                                                   Repair kit  Type
        Ceramic cartridge Ø 35mm with base
        Ref.s 25061T1, 2506T1, 2506T2, 2506T3, 2542, 2599, 5625, 5626, 5825, 5826, 6692, 6693,   NS262  -
        6892 & 6893
        Ceramic cartridge Ø 40mm without base
        Ref.s 2510, 2519, 2597,                                     N148AA75  -
        2211, 2211L, 2542 & 2599 (before 12/2017)
        Ceramic cartridge Ø 40mm without base
        Ref.s 2211, 2211L & 2597                                    N109AG75  E
        Ceramic cartridge Ø 45mm without base
        Ref.s 5650T2, 5650T3 & 5652                                  NS565    -

        TEMPOSTOP TAPS & VALVES

                                                    Timing    Repair kit  Complete   Type
                                                     (sec.)          cartridge
        745100, 746000, 748626                        7     753005   743005   -
        745440, 748126                                7     753005   743305   F
        737152, 737202                                3     753303   743323   -

        HANDS FREE CONTROLS
        TEMPOGENOU 734100, 735000, 735400, 735447, 73544715  7  -    743305   F
        MIXFOOT 739000, 739100, 739102                -     753739     -      -
        MONOFOOT 736001, 736101, 736102               -     753736     -      -

        SOAP DISPENSERS
                                                                     Complete
                                                           Repair kit        Type
                                                                     cartridge
        729
        729008, 729108, 729508                             729302    729308   -
        729012, 729112, 729512                             729302    729312   -
        729150                                             729302    729303   -
