Page 179 - water-controls-for-public-and-commercial-places

TEMPOFLUX time flow urinal valves /

• Exceptional water savings: 60%
• Comfort: soft-touch operation
• Simple to maintain: innovative stopcock and flow rate adjustment system integrated in the wall plate

TEMPOFLUX
Exposed time flow urinal valve

URINALS

• For standard or siphon action urinals.
• For wall-mounted, exposed installation.
• Soft-touch operation.
• Time flow ~3 seconds.
• Flow rate pre-set at 0.15 L/sec. at 3 bar, can be adjusted up to 0.3 L/sec.
• Innovative stopcock and flow rate adjustment system integrated
in the escutcheon (patented).
• Complies with European standard EN 12541 (class II acoustic level).
• Compatible with rain water.
• Chrome-plated solid brass body M½".
• With chrome-plated neck tube.
• Angled for recessed inlet.
• Suitable for people with reduced mobility.
• 30-year warranty.

1/2" 1/2" 1/2"
15 15 15
Ø 16 Ø 16
Ø16
TEMPOFLUX exposed kit for DELABIE urinals 50 50 50
For FINO urinal 778759 £173.94 350 330 20 320
For DELTA urinal 778757 £173.94
TEMPOFLUX exposed kit for urinals with rim 3/8" Ø 35
3/8"
For standard urinal (50mm gap from wall)
(type ALLIA Blagnac or DURAVIT Jim, Starck, D-code or IDEAL 778755 £169.18
STANDARD Axif or LAUFEN Caprino or ROCA Mini or VB
O.Novo etc.)
778759 778757 778755
Urinals 177
