/ Additional fittings Unions and neck tubes

Elbow union Neck tube Neck tube
With or without stopcock For siphon action urinals For standard or siphon action urinals

• Retractable nut. • F¾" Ø 35mm. • F½" Ø 35mm.
• Chrome-plated brass. • IDEAL STANDARD Prival 3803. • ALLIA GEBERIT Satolas 43650/43651
• L. 30mm. • NOVOBOCH Mistal or Vasco. or Blagnac 3560.
• 30-year warranty. • ROCA wall-mounted. • DURAVIT Ben 848.7, Pago 839.6, Jim or Neiße.
• SELLES 8620 or Mistal. • IDEAL STANDARD Pindard.
• VILLEROY & BOCH Targa 7502/7504 • LAUFEN Como.
1/2" Ø 50 1/2" Ø 50 or Esta 7508. • NOVOBOCH Oural 600.
• 30-year warranty. • PORCHER Axif.
• SELLES Euroline.
30 27 • SPHINX Eurobase.
30 1/2" 30 1/2" • VILLEROY & BOCH Java, Toboga, Troja,
Magnum, Targa, Esta.
3/4" 1/2"
836015 838015 • 30-year warranty.

Elbow STOP union with stopcock 20 20
165 165
MF½", H. 30mm 836015 £51.63
M½" - F¾", Ø 50 Ø 35 Ø 50 Ø 35
H. 30mm ± 2mm 836020 £49.96
Elbow union without stopcock
759000 752000
MF½", H. 27mm 838015 £37.86
M½" - F¾", H. 29mm 838020 £40.15 Neck tube F¾" Ø 35mm 759000 £39.76 Neck tube F½" Ø 35mm 752000 £35.73

Neck tube Neck tube Neck tube
For DELABIE urinals For ALLIA / SELLES urinals For I.S. / PORCHER urinals

• F½". • F½" with water nozzle. • IDEAL STANDARD Exposed 3873.
• DELABIE FINO or DELTA. • ALLIA GEBERIT Aubagne. • PORCHER Exposed 2642/2651.
• 30-year warranty. • SELLES 8418. • 30-year warranty.
For matching urinals see DELABIE "Stainless • 30-year warranty.
Steel Sanitary Ware" catalogue (DOC 750UK).
1/2"
1/2"
1/2"
1/2"
Ø 12
140 13
327 240 14 245
Ø 39 3/8"
170°
753000
Ø 39
3/8" 3/8"
757135 757162 751000
Neck tube F½", for I.S. / PORCHER urinals
IDEAL STANDARD F½" -
Neck tube F½", for DELABIE urinals Neck tube F½" for F⅜" Exposed 3873
ALLIA / GEBERIT
FINO 757135 £51.77 751000 £50.85 753000 £23.65
Aubagne, PORCHER F½" - F⅜"
DELTA 757162 £64.48 SELLES 8418 urinals Exposed 2641/2651

182 Urinals
