Page 107 - Water_Controls_for_Public-Commercial

TEMPOMIX time flow shower panels /

• Exceptional water savings: 80%
• Comfort: temperature selection directly on the single control mixer, soft-touch operation, rain-effect spray
• Vandal-resistant: stainless steel panel, concealed fixings, solid brass shower head and shower valve

TEMPOMIX satin stainless steel
Time flow shower panel with fixed shower head

• Large satin stainless steel shower panel for wall-mounted,
exposed installation.
• TEMPOMIX mixer with adjustable maximum temperature limiter.
• Soft-touch operation.
• Time flow ~30 seconds.
• Flow rate 6 lpm at 3 bar, comfortable rain-effect spray.
• Chrome-plated, tamperproof ROUND shower head
with automatic flow rate regulation.
• Integrated soap dish.
• M½" connections. SHOWERS
• Concealed fixings.
• Filters and non-return valves.
• Stopcocks.
• Suitable for people with reduced mobility.
• 30-year warranty.

250
40
80 1/2" 250 100
65-105 170-210 125

1210 1210
1115 1/2" 1115

500
585
85

790204 790214

TEMPOMIX time flow shower panel with fixed shower head
Top inlet via in-line stopcocks 790204 £972.75
Concealed inlet via flexibles 790214 £972.75
We recommend installing a TMV (see page 143) and a floor trap (see page 131)
Option: extensions for shower panels (see page 136)

Showers 105
