/ TEMPOMATIC 4 recessed electronic urinal valves

TEMPOMATIC 4 RECESSED:
100% WATERPROOF RECESSED HOUSING, MODULAR AND ADAPTABLE

Modular 100% waterproof
DELABIE's recessed housing can be attached from the sides, front Standard housings on the market are designed to be cut to size
or back, to be fixed to plasterboard rails, load-bearing walls or even flush to the wall, which increases the risk of leaks between
thin panels. The installation is therefore modular, and adapts to suit the wall and the collar.
any project. DELABIE's recessed housing is equipped with a collar with an
integrated seal, that clips onto the housing once the wall finish
is in place (patented system). It is completely waterproof
without silicone. Any condensation is evacuated via the plate.
The wall stays intact throughout.

Plasterboard rails Load-bearing walls Thin panels

Adaptable
The ideal positioning of the collar allows the housing to be cut to size
lengthwise depending on the wall thickness, whilst still guaranteeing Collar with integrated waterproof seal
a complete waterproof seal. The housing adapts to all wall depth
requirements, thick or thin, from 10 to 120mm.
Minimal servicing and simple to maintain
Maintenance is carried out from the front by simply removing
the control plate.
The technical elements are accessible and the component parts
parts come pre-assembled. An LED indicates when the batteries
need to be replaced. Integrated in the plate, they can be replaced
without shutting off the water or removing the valve.
The TEMPOMATIC 4 is compatible with sea water, grey water
and rainwater.
Making protection from frost and in-depth maintenance easier,
Thick wall finish Narrow wall finish
Max. 120mm Min. 10mm the valve can be disconnected and removed from the inside,
without removing the housing.
Quick and easy to install Exceptional water savings
The TEMPOMATIC 4 can be connected to standard pipework Thanks to its optimised flow rate and time flow, the TEMPOMATIC 4
or "pipe in pipe". rinse provides just the necessary flush volume and, therefore,
The hydraulic connection is made from the outside of the housing. the best compromise between water consumption and efficacy.
During the installation, the solenoid valve, the filter and the stopcock It also features the high-frequency mode.
are replaced by a temporary casing to facilitate and ensure a safe For more information see page 161.
system flush, without damaging the technical elements.
Hygiene
The TEMPOMATIC 4 recessed urinal flush rinses automatically after
each user leaves. No manual contact prevents the spread of germs
Definitive valve
by hand. The hygienic duty flush prevents bacterial proliferation
and the problem of vacuums.
The TEMPOMATIC 4 is supplied with a reduced-stagnation solenoid
valve. For more information see page 161.

Design
The TEMPOMATIC 4 control plate has a timeless design,
Temporary casing available in bright polished, satin, or black glass finish.
Compact and discreet, it fits perfectly in any type of public
and commercial building. Its smooth surface limits the build-up
of dirt and facilitates cleaning.
This new concept combines design and functionality:
the electronics are integrated directly in the wall plate.

166 Urinals
