TEMPOCHASSE time flow direct flush systems /

• Efficiency and water savings: direct flush reduces the risk of leaks, powerful flush is available instantly
• Hygiene: no cistern: no water stagnation (reduces bacterial development)
• Vandal-resistant: chrome-plated solid brass, shock-resistant mechanism, for recessed or cross wall installation

TEMPOCHASSE TEMPOCHASSE TEMPOCHASSE
Recessed WC flush valve Exposed WC flush kit Exposed WC flush valve

• Flush system without cistern: directly • Flush system without cistern: directly • Flush system without cistern: directly
connected to pipework. connected to pipework. connected to pipework.
• Satin stainless steel control plate 320 220mm. • For wall-mounted, exposed installation. • For wall-mounted, exposed installation.
• Time flow ~7 seconds. • Time flow ~7 seconds. • Time flow ~7 seconds.
• Vacuum breaker. • Vacuum breaker. • Vacuum breaker.
• In-line cast brass stopcock and flow rate/ • F1" chrome-plated brass stopcock • Chrome-plated brass body and push-button.
flush volume adjuster. and flow rate/flush volume adjuster. • Shock-resistant mechanism.
• Brass body and chrome-plated push-button. • Chrome-plated brass body and push-button. • In-line inlet M1¼".
• Shock-resistant mechanism. • Shock-resistant mechanism. • Base flow rate: 1 L/sec. at 1 bar dynamic
• In-line inlet F1". • Connection washer Ø 32/55mm with clamp. pressure.
• Connection washer Ø 32/55mm. • Base flow rate: 1 L/sec. at 1 bar dynamic • Compatible with rain water.
• Base flow rate: 1 L/sec. at 1 bar dynamic pressure. • 30-year warranty.
pressure. • Compatible with rain water.
• Compatible with rain water. • Bright polished stainless steel elbow flush
• 30-year warranty. tube Ø 32mm with nut and collar. 1"1/4
• 30-year warranty.
This model does not have a waterproof recessed 110
housing. The installer must ensure that 1"1/4
33
the recessing area is waterproof and any leaks
or condensation can drain away (see installation CISTERN-LESS
guide). 760000
1" WCs
1"
100 min
1" 92
Ø 32 1"1/4
290 x 165 x 100 320 x 220 865 max 205 max 764000

1"
42
65-85
33 1"1/4
Ø 55 Ø 55
760004 765000
Ø 32
760220 TEMPOCHASSE WC exposed kit
For conventional WC pans
With in-line stopcock 760004 £305.01 TEMPOCHASSE WC exposed
With push-button 760000 £138.58
With elbow stopcock 760005 £294.93
TEMPOCHASSE WC For slop hoppers In-line stopcock 764000 £86.72
760220 £370.59
recessed With in-line stopcock Elbow stopcock 765000 £76.68
We recommend a flush tube (see page 232) and straight flush tube 760460 £346.54 We recommend a flush tube (see page 232)

Cistern-less WCs 231
