/ TEMPOFIX 3 with TEMPOFLUX 2 frame systems for direct flush


                  •  Efficiency and water savings: direct flush reduces the risk of leaks, powerful flush is available instantly, 3L/6L dual flush
                  •  Specifically designed for public and commercial places: space saving, easy to clean, withstands intensive use
                  •  Easy to install: frame system delivered pre-mounted
                  •  Hygiene: no cistern: no water stagnation (reduces bacterial development)


          TEMPOFIX 3 with TEMPOFLUX 2
          Frame system for drywall

                                                               • Self-supporting black powder-coated steel frame.
                                                               • Frame height can be adjusted from 0 - 200mm (with 1m mark).
                                                               • Ø 32mm flush tube with Ø 55mm connection washer.
                                                               • ABS soil pipe with HDPE sleeve connector, Ø 110mm outlet
                                                                with waterproof seal, with 2 setting positions.
                                                               • Delivered pre-mounted.
                                                               • For walls from 10 - 35mm.
                                                               Fitted with TEMPOFLUX 2 time flow direct flush valve:
                                                               • Flush system without cistern: directly connected to pipework.
                                                               • Ø 195mm chrome-plated metal control plate with concealed fixings.
                                                               • Available with 6L single flush can be adjusted to 9L, or 3L/6L dual
                                                                flush can be adjusted to 2L/4L.
                                                               • Soft-touch operation.
                                                               • Vacuum breaker.
                                                               • Stopcock and flow rate/volume adjuster.
                                                               • Brass body and shock-resistant, scale-resistant mechanism.
                                                               • In-line inlet M¾".
                                                               • Acoustic level complies with European standard EN 12451 class II.
                                                               • Supply pipe diameter: Ø 20mm minimum internal pipe diameter
                                                                is required at all points (connectors included).
                                                               • Base flow rate: 1 L/sec at 1 bar dynamic pressure.
                                                               • Compatible with rain water.
                                                               • Suitable for rimless WC pans and for people with reduced mobility.
                                                               • 30-year warranty.























                                                                                    Ø 195           10-35
                                                                                              3/4"






                                                                           1000-1320




                                                                                            300-620
          TEMPOFIX 3 WC frame system with TEMPOFLUX 2 (for drywall from 10 - 35mm)
                                             578305DE  £516.31
          3L/6L dual flush (DELABIE patented)                                    Ø 110
                                             + 578222  £91.78
                                                                                180-230        165
                                             578305DE  £516.31                   350          157-177
          6L single flush (can be adjusted to 9L)
                                             + 578212  £91.78
          Options: wall fixings, sleeve connector and kit for accessible WCs (see page 233)
                                                                                  578305DE + 578222
          228 Cistern-less WCs
